| US$298.00 | 10 Pieces (MOQ) |
PROCESSOR | CPU | Onboard Intel Celeron Baytrail-D/I/M Processor |
| RAM | Onboard 2GB/4GB DDR3 1066/1333MHz,1 RAM slot to expand 8GB DDR3 RAM max. | |
| STORAGE | Onboard SSD16/32/64/128G (optional) SATA and MSATA,HDD or SSD (optional) | |
| NETWORK | 2*RTL8111E RJ45 1000M LAN | |
I/O INTERFACE | 5*RS-232, 1*RS422/485,2*DB9 RS-232 3* 3pin RS-232 2*USB2.0,2*USB3.0, 1*14BIT GPIO Connector, 1*LINE OUT 1*MIC, 2*Wifi Antenna port 1*POWER ON/OFF switch 1*VGA Maximum resolution 2048x1536 1*HDMI Maximum 3200*2000@60HZ | |
| EXPANSION BUS | 1* full size Mini PCIE slot | |
| WATCHDOG | 0-255 second, Sample code optional | |
| Physical characteristics | Size(mm) | 290*221*53.8mm |
| Weight(kgs) | 2.43kg | |
| O/S SUPPORT | Operation System | Support Windows 7/Windows8/Windows8.1/Windows10/Linux/Android |
| POWER SUPPLY | INPUT | Single input DC12V 5A +/-5% |
| Power Consumption | 20W | |
LED DISPLAY | DISPLAY TYPE | 10inch TFT LED |
| Maximun Resolutions | 800*600 | |
| View | 80 (LEFT), 80 (RIGHT), 70 (UP), 70 (DOWN) | |
| Lumens (cd/m²) | 350cd/m² | |
| Contrast | 400:1 | |
| Backlight Life | 30,000 hrs (Min.) | |
TOUCH PANEL | TYPE | 4 Wires Resistive touch panel |
| Light Transmittance | ≥85% | |
| Controller Interface | USB port | |
| Durability(Touch Times) | >35 million times | |
ENVIRONMENT | Working Temperature | -20ºC ~ +60ºC |
| Storage Temperature | -40ºC ~ +85ºC | |
| Relative humidity | 0% ~ 90%Relative humidity, none condensation | |
| EMC | CE, FCC Class B, BSMI | |
| CERTIFICATE | CB, CCC, BSMI, UL | |
| Front panel protection | IP65 |
