US$7,000.00-9,000.00
|
1 Piece
(MOQ)
|
Basic Info.
Model NO.
CD6236B CD6240B CD6250B CD6260B
Processing Accessory
Metal
Guide Rail
Horizontal Guide Rail
Tool Holder
4 Way Tool Post
Controlling Mode
Artificial
Certification
CE, RoHS, ISO 9001
Swing Over Cross Slide
225mm
Spindle Speed
22-1800rpm(15 Steps)
Transport Package
Plywood Case
Production Capacity
10 PCS/Month
Product Description
CDB SERIES LARGE SPINDLE HOLE PRECISION LATHE
Large spindle bore of 65mm
Main spindle dynamic balanced, and supported at 2 points with taper roller bearings of Harbinbrand
Outward appearance featuring large plains, making the machine more good-looking
Gapped bed ways, which are super-audio frequency hardened
All gears hardened and ground by Reishauer grinding machine
Leadscrew and feed rod interlocked, both with overload protection
Automatic feed stopper
Configuration variable totally according to orders:
Metric or inch system; Right or left hand wheel; Large plane type; Halogen lamp; Quick change tool past; DRO; T-slot compound; Chuck guard; Leadscrew hood; Rapid traverse motor; Electromagnetic brake; Forced lubrication system.
| STANDARD ACCESSORIES | OPTIONAL ACCESSORIES |
3-jaw chuck
Center$center sleever
Wrenched
Oil gun
Operation manual
Steady rest
follow rest
4-jaw chuck
Face plate
Thread dial
Longitudinal touch stop | Live center
Quick change tool post
Taper copy ruler
4-position longitudinal touch stop |
SPECIFICATIONS:
| MODEL | CD6236B | CD6240B | CD6250B | CD6260B |
| CAPACITIES | Max. swing over bed (mm) | 360 | 400 | 500 | 600 |
| Max. swing over cross slide(mm) | 185 | 225 | 325mm | 360 |
| Center distance (mm) | 1000, 1500, 2000mm |
| Max swing in gap (mm) | 490 | 530 | 630 | 730 |
| Valid length of gap | 260mm |
| Bed width | 330mm |
| HEADSTOCK | Spindle hole | 65mm |
| Spindle nose | ISO-C6 or ISO-D6 |
| Spindle taper | Metric 70mm |
| Spindle speeds (Number) | 22-1800rpm (15 steps) |
| FEEDS | Metric threads range (Kinds) | 0.5-28mm (66kinds) |
| Inch Threads range (Kinds) | 1-56 /inch(66kinds) |
| Module threads range (Kinds) | 0.5-3.5mm (33kinds) |
| Diametral threads range (Kinds) | 8-56 DP(33kinds) |
| Longitudinal fees range (Kinds) | 0.072-4.038mm/rev(0.0027-0.15 inch/rev) (66kinds) |
| Cross feeds range (Kinds) | 0.036-2.019mm/rev(0.0013-0.075 inch/rev) (66kinds) |
| Rapid traveling speed of carriage | 5m/min (16.4ft/min) |
| Leadscrew size: Diameter/Pitch | 35mm/6mm |
| CARRIAGE | Cross slide travel | 300mm |
| Compound rest travel | 130mm |
| Cross-section size of toolshank | 20*20mm | 25*20mm | 25*25mm |
| TAILSTOCK | Taper of tailstock sleeve | Morse No.5 |
| Diameter of tailstock sleeve | 65mm |
| Travel of tailstock sleeve | 120mm |
| MOTOR | Main drive motor | 4.0kw or 5.5kw or 7.5kw | 7.5kw |
| Coolant pump motor | 0.125kw |
| Rapid traverse motor | 0.12kw |
| Packing Size (L*W*H) (mm) |
| Center Distance 1000mm | 2420*1150*1800 |
| 1500mm | 2920*1150*1800 |
| 2000mm | 3460*1150*1800 |
>>
