Product Details
Product Description
Product Description
explain
Ti MSP series ultra-low power microcontrollers have a wide variety, and each member device is equipped with different peripheral sets to meet the needs of various applications. This architecture works with a variety of low-power modes and is optimized to extend battery life in portable measurement applications. The device has a powerful 16 bit RISC CPU
16 bit register and constant generator help to achieve higher coding efficiency. This digital controlled oscillator (DCO) enables the device to wake up from low-power mode to active mode within 3.5 µ s (typical).
Msp430f543xa and msp430f541xa series microcontroller configurations include three 16 bit timers, a high-performance 12 bit ADC, up to four USCIS, a hardware multiplier, DMA, RTC module with alarm function and up to 87 I / O pins.
characteristic
• low supply voltage range:
3.6V to 1.8V
• ultra low power consumption
– active mode (AM):
All system clocks are active
At 8MHz, 3.0V and when the flash program is executed
230 µ A / MHz (typ.)
At 8MHz, 3.0V and when the ram program is executed
110 µ A / MHz (typ.)
– standby mode (lpm3):
Real time clock (RTC) with crystal, watchdog, power monitor
Available, full ram hold, fast wake-up:
1.7 µ a at 2.2V and 2.1 µ a at 3.0V (typ.)
Low power oscillator (VLO), universal counter, watchdog and power
Source monitor available, full ram hold, fast wake-up:
1.2 µ a at 3.0V (typ.)
– off mode (lpm4):
Full ram hold, power monitor available, fast wake up:
1.2 µ a at 3.0V (typ.)
– off mode (lpm4.5):
0.1 µ a at 3.0V (typ.)
• at 3.5 μ Wake up from standby mode within s (typical)
• 16 bit RISC architecture
– extended memory
– system clock up to 25MHz
• flexible power management system
– fully integrated LDO with programmable regulated core supply voltage
– power supply voltage monitoring, monitoring and undervoltage protection
• unified clock system
– phase locked loop (FLL) control loop for frequency stability
– low power low frequency internal clock source (VLO)
– low frequency trim internal reference source (Ref)
– 32kHz crystal oscillator
– high frequency crystal oscillator up to 32mhz
• 16 bit timer TA0 with five capture / compare registers,
Timer_ A
• 16 bit timer TA1 with three capture / compare registers,
Timer_ A
• 16 bit timer with seven capture / compare shadow registers
TB0，Timer_ B
• up to 4 universal serial communication interfaces (usci)
– USCI_ A0、USCI_ A1、USCI_ A2 and usci_ A3
All support:
• enhanced universal asynchronous transceiver (UART) supports automatic wave
Specific rate detection
• infrared data communication (IrDA) encoder and decoder
• synchronous SPI
– USCI_ B0、USCI_ B1、USCI_ B2 and usci_ B3
All support:
• I
2C
• synchronous SPI
• 12 bit analog-to-digital converter (ADC)
– internal datum
– sample and hold
– auto scan feature
– 14 external channels, 2 internal channels
• hardware multiplier supports 32-bit operation
• serial on-board programming without external programming voltage
• 3-channel internal DMA
• basic timer with RTC features
• the device comparison summarizes the available product family members
Scope of application
• analog and digital sensor systems
• digital motor control
• remote control
• thermostat
• digital timer
• handheld instruments
>>
