| US$13,357.00-16,029.00 | 1 Piece (MOQ) |
| MODEL | CF100B-7 | CF185B-7 | CF185B-10.5 | CF275B-7 | CF400B-7 | CF390B-10.5 |
| Air End Type | Rotary Twin Screw, Single stage | Rotary Twin Screw, Single stage | Rotary Twin Screw, Single stage | Rotary Twin Screw, Single stage | Rotary Twin Screw, Single stage | Rotary Twin Screw, Single stage |
| Air Outlets | 3/4'' x 2 | 3/4'' x 3 | 3/4'' x 3 | 3/4'' x 2 + 1-1/4'' x 1 | 3/4'' x 3 + 2' x 1 | 3/4'' x 3 + 2' x 1 |
| Free Air Delivery | 100 CFM / 2.8 m3/min | 185 CFM / 5.2 m3/min | 185 CFM / 5.2 m3/min | 275 CFM / 7.8 m3/min | 400 CFM / 11.2 m3/min | 390 CFM / 11 m3/min |
| Working Pressure | 7 bar / 101.5 psi | 7 bar / 101.5 psi | 10.5 bar / 152.25 psi | 7 bar / 101.5 psi | 7 bar / 101.5 psi | 10.5 bar / 152.25 psi |
| Engine Model | ISUZU | ISUZU | ISUZU | ISUZU | CUMMINS | CUMMINS |
| Fuel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel |
| Emission | China Stage II | China Stage II | China Stage II | China Stage II | China Stage II | China Stage II |
| Engine Type | 4 cylinder, Direct-injection | 4 cylinder, Direct-injection | 4 cylinder, Direct-injection | 4 cylinder, Direct-injection | 4 cylinder, Direct-injection | 4 cylinder, Direct-injection |
| Displacement | 2.771 L | 2.771 L | 2.771 L | 2.771 L | 3.9 L | 5.9 L |
| L X W X H | 1880*915*1230 mm | 2100*980*1100 mm | 2280*1224*1260 mm | 2280*1224*1260 mm | 2657*1355*1466 mm | 2970*1350*1465 mm |
| Weight | 820 kg | 930 kg | 1100 kg | 1100 kg | 1850 kg | 1920 kg |
| Note: Please feel free to contact us if any more customized requirements ! | ||||||
