CNC Slant Bed Linear Guideway Lathe Turning Machine Center

Product Description

CLK6336 SLANT BED CNC LATHE MACHINE
1. CLK6336 SLANT BED CNC LATHE MACHINE SPECIFICATION

	unit	CLK6336
Max. swing over bed	mm	Φ390
Max. swing over cross slide	mm	Φ130
Max. processing length	mm	200
X/Z axis travel	mm	400/300
Spindle unit	mm	140(170 optional)
Spindle nose		A2-5
Spindle bore	mm	48(56 optional)
Spindle drawing pipe diameter	mm	40(45 optional)
Spindle speed	rpm	4000(3500 optional)
Chuck size	inch	6/8
Spindle motor	kw	3.7/5.5
X/Z feed motor power	kw	1.5
X/Z feed motor torque	N.m	6/6
X/Z position accuracy	mm	0.016/0.016
X/Z repeatability	mm	0.006/0.006
X/Z rapid feed speed	m/min	18/15
Cutting tool shape size	mm	20*20
Total power capacity	kva	9(11 optional )
Guide type		Taiwan linear guide way
Machine dimension (L*W*H)	mm	2200×1340×1710
N.W.	KG	2200

2.MACHINE FEATURES
45 degrees slant bed CNC lathe
Higher accuracy Taiwan linear
Chip conveying capacity is large and convenient, customer could choose
chip conveying in the front or in the back
Screw pre-stretching structure
Gang type tool post
3. CLK6336(S) SLANT BED CNC LATHE USAGE
This machine is applicable to automobile, motorcycle, electronics, aerospace, oil and other
industry. It could turn the conical surface, circular arc surface, end face of the rotary parts, could
also turn various metric and inch threads etc, with higher efficiency and higher precision in bulk.
4. CLK6336(S) SLANT BED CNC LATHE STANDARD ACCESSORIES
GSK980TDC or Siemens 808D NC system
servo motor 3.7 kw
4 station gang type tool post
6" domestic thru-hole type hydraulic chuck
8" hydraulic chuck (thru-hole type and none thru-hole type are available)
5. CLK6336(S) SLANT BED CNC LATHE OPTIONAL ACCESSORIES
NC System: KND1000Ti, Fanuc Oi Mate-T
Main Motor: Servo5.5/7.5KW
Inverter 7.5KW
Turret: 4 station electric turret , 6 station electric turret
Chuck: 6″Non-through hole hydraulic chuck
8″Non-through hole hydraulic chuck (Taiwan)
8″through hole hydraulic chuck(Taiwan)
Chip conveyor
Steady Rest
Other optional item: Driving tool turret, automatic feeding device and manipulator.

---
