800-1600 mm Basket Diameter Centrifuge with Automatic Bottom Scraper Discharge System

Product Description

Flat Plate Automatic Bottom Scraper Discharging Centrifuge
Introducing the 800-1600 mm Basket Diameter Centrifuge with Automatic Bottom Scraper Discharge System by Hunan Zhongyi Centrifuge Co., Ltd. This centrifuge features an automatic bottom scraper that ensures efficient and convenient discharge of materials. Perfect for various industrial applications.
Introduction
PGZ Flat Plate Automatic Lower Discharge Centrifuge
The PGZ Flat Plate Automatic Lower Discharge Centrifuge is a high-performance centrifugal filtering device designed for intermittent operation with lower discharge. This innovative product eliminates the need for a traditional hanging column base, simplifying the installation process. With its simple structure, beautiful appearance, and easy cleaning and disinfection, this centrifuge is a convenient choice.
The PGZ Centrifuge features an absorption type isolator, ensuring no vibration interference to the foundation ground and surrounding equipment. All elements in contact with materials are made of corrosion-resistant stainless steel, guaranteeing durability and longevity. The high-efficiency washing nozzle ensures thorough cleaning without any blind areas.
Equipped with a frequency converter and PLC programmable controller, this centrifuge offers soft start, stepless speed regulation, electric feedback braking, and on-site speed regulation. Safety features include cover opening protection, filter cake thickness detection, vibration switch protection, and speed monitoring. The entire process of feeding, washing, dehydration, and unloading is fully automatic.
The centrifuge is controlled in two places, with an operation box conveniently located on-site. The upper cover is a quick-opening type, driven by air pressure to avoid oil pollution and maintain environmental health.
Application
The PGZ Flat Plate Automatic Lower Discharge Centrifuge is suitable for separating suspensions containing solids with a particle size greater than 0.05mm. It is particularly useful for separating materials that are not accessible to personnel. This centrifuge finds applications in various industries, including food, pharmaceutical, health products, and national defense.
Machine Structure
Manufacturer: Hunan Zhongyi Centrifuge Co., Ltd.
Product Name: 800-1600 mm Basket Diameter Centrifuge with Automatic Bottom Scraper Discharge System
Technical Parameters

Mame	Flat Plate Automatic Bottom Scraper Discharging Centrifuge PGZ
Model	PGZ800	PGZ1000	PGZ1250	PGZ1250 (Slant distributing )	PGZ1360	PGZ1600
Basket diameter (mm)	800	1000	1250	1250	1360	1600
Working volume(L)	110	140	340	400	450	780
Max.load (kg)	135	195	450	520	580	1050Ma
Max. speed r/min)	1500	1000	1000	1000	900	850
Max G .force	1008	560	700	700	617	647
Main motor (kw)	7.5	11/15	22/30	1.5/22/30	30/37	37
Dimensions (mm)	1685/1200/1510	2010/1450/1720	2260/1800/1900	2470/1850/2718	2500/1960/2500	3000/2400/2700
Weight (kg)	2200	3000	4800	5800	5800	8500

800-1600 mm Basket Diameter Centrifuge with Automatic Bottom Scraper Discharge System
Introducing the 800-1600 mm Basket Diameter Centrifuge with Automatic Bottom Scraper Discharge System from Hunan Zhongyi Centrifuge Co., Ltd. This centrifuge is designed to meet your specific needs and provide efficient and reliable separation of materials.
Key Features:
Material: The material contact part can be made of ordinary stainless steel, special stainless steel, or titanium alloy, ensuring compatibility with a wide range of materials.
Motor Type: Choose between an ordinary or explosion-proof single-speed motor, depending on your requirements.
Personalized Design: We offer personalized design and manufacturing options to meet your unique specifications.
GMP Specifications: This centrifuge can be designed and manufactured according to GMP specifications, ensuring compliance with industry standards.
With the Automatic Bottom Scraper Discharge System, this centrifuge offers convenient and efficient material discharge. The technical parameters will be subject to the product specification, and other technical requirements can be negotiated.
Detailed Photos
Packaging & Shipping
Company Profile
Company Profile
Welcome to Hunan Zhongyi Centrifuge Co., Ltd. We specialize in the production of high-quality centrifuges with basket diameters ranging from 800-1600 mm. Our centrifuges are equipped with an automatic bottom scraper discharge system, ensuring efficient and convenient operation. Choose our centrifuges for reliable performance and easy maintenance.
800-1600 mm Basket Diameter Centrifuge with Automatic Bottom Scraper Discharge System
Hunan Zhongyi Centrifuge Co., Ltd. specializes in the design, production, and service of centrifuges. With over 60 years of experience, we are a trusted high-tech equipment manufacturing enterprise. As a member of the China Separation Machinery Industry Association, a national high-tech enterprise, and a private science and technology enterprise in Hunan Province, we are committed to delivering quality products and exceptional service.
Our 800-1600 mm Basket Diameter Centrifuge with Automatic Bottom Scraper Discharge System is one of our flagship products. It is designed to provide efficient separation and discharge of materials. With a strong technical force and an excellent management team, we ensure that our centrifuge meets the highest standards of quality and reliability.
Key Features:
Automatic Bottom Scraper Discharge System: The centrifuge is equipped with an automatic bottom scraper that allows for easy and efficient discharge of separated materials.
Wide Range of Basket Diameters: Our centrifuge is available in various basket diameters ranging from 800 mm to 1600 mm, allowing you to choose the size that best suits your needs.
Reliable Performance: With our advanced production process and quality control measures, our centrifuge delivers reliable and consistent performance.
Easy to Use: The centrifuge is designed for user-friendly operation, making it easy to set up and operate.
Durable Construction: Made from high-quality materials, our centrifuge is built to withstand the rigors of continuous use.
Whether you need to separate solids from liquids or perform other separation processes, our 800-1600 mm Basket Diameter Centrifuge with Automatic Bottom Scraper Discharge System is the ideal choice. Contact us today to learn more about our centrifuge and how it can benefit your operations.
Certifications
Product Description:
Hunan Zhongyi Centrifuge Co., Ltd. offers the 800-1600 mm Basket Diameter Centrifuge with an Automatic Bottom Scraper Discharge System. This centrifuge is designed for efficient and convenient separation of materials, making it ideal for various industrial applications.
Product Name: 800-1600 mm Basket Diameter Centrifuge with Automatic Bottom Scraper Discharge System
Company Name: Hunan Zhongyi Centrifuge Co., Ltd.
Description: Experience efficient centrifugation with our 800-1600 mm Basket Diameter Centrifuge. Equipped with an Automatic Bottom Scraper Discharge System, it ensures easy and convenient removal of materials. Perfect for various industrial applications.
Hunan Zhongyi Centrifuge Co., Ltd. offers the 800-1600 mm Basket Diameter Centrifuge with an Automatic Bottom Scraper Discharge System. This centrifuge is designed for efficient and convenient separation of materials. With its automatic discharge system and bottom scraper, it ensures easy and hassle-free operation. Ideal for various industries, this centrifuge guarantees reliable performance and high productivity.

---
