Product Details
Product Description
Product Description
POWEREDGE R640Uncompromising performance and density
The PowerEdge R640 is the ideal dual-socket, 1U platform for dense scale-out data center computing. The R640 combines density, performance and scalability to optimize application performance and data center density.
Maximize application performance and density
The scalable business architecture of the R640 is designed to maximize application performance and provide the flexibility to optimize configurations based on the application and use case. With the R640 you can create an NVMe cache pool and use either 2.5” or 3.5” drives for data storage. Combined with up to 24 DIMM’s, 12 of which can be PMems or NVDIMMs, you have the resources to maximize application performance with the optimum configuration in only a 1U chassis.
• Simplify deployments and speed deployments with Dell EMC ready nodes for VSAN.
• Maximize storage performance with up to 10 NVMe drives or 12 2.5” drives.
• Scale compute resources with 2nd Generation Intel® Xeon® Scalable processors and tailor performance based
on your unique workload requirements.
Automate maintenance with Dell EMC OpenManage
The Dell EMC OpenManage™ portfolio helps deliver peak efficiency for PowerEdge servers, delivering intelligent, automated management of routine tasks. Combined with unique agent-free management capabilities, the R640 is simply managed, freeing up time for high profile projects.
• Simplify management with the OpenManage Enterprise™ console, with customized reporting and automatic discovery.
• Take advantage of QuickSync 2 capabilities and gain access to your servers easily through your phone or tablet.
Guard your data center with built in security
Every PowerEdge server is designed as part of a cyber resilient architecture, integrating security into the full server life cycle. The R640 leverages new security features built-into every new PowerEdge server strengthening protection so you can reliably and securely deliver accurate data to your customers no matter where they are. By considering each aspect of system security, from design to retirement, Dell EMC ensures trust and delivers a worry-free, secure infrastructure without compromise.
• Rely on a secure component supply chain to ensure protection from factory to the data center.
• Maintain data safety with cryptographically signed firmware packages and Secure Boot.
• Protect your server from malicious malware with iDRAC9 Server Lockdown mode (requires Enterprise or Datacenter license).
• Wipe all data from storage media including hard drives, SSDs and system memory quickly and securely with System Erase.
| PowerEdge R640 |
| Features | Technical Specification |
| Processor | Up to two 2nd Generation Intel® Xeon® Scalable processors, up to 28 cores per processor |
| Memory | 24 DDR4 DIMM slots, Supports RDIMM /LRDIMM, speeds up to 2933 MT/s, 3TB max
Up to 12 NVDIMM, 192 GB Max
Up to 12 Intel® Optane™ persistent memory PMem, 6.14TB max, (7.68TB max with PMem + LRDIMM)
Supports registered ECC DDR4 DIMMs only |
Storage controllers
Internal boot | Internal Controllers: PERC H330, HBA330, HBA350i (adapter only), H730P, H740P, H750 (adapter only)
External Controllers: H840, 12 Gbps SAS HBA, HBA355e (adapter only, non-RAID)
Software RAID: S140
Boot Optimized Storage Subsystem (BOSS): HWRAID 2 x M.2 SSDs 240 GB, 480 GB
Internal Dual SD Module1 |
| Drive bays | Front drive bays: Up to 10 x 2.5” SAS/SATA (HDD/SSD) with up to 8 NVMe SSD max 76.8TB or up to 10 NVMe drives max 64TB,
or up to 4 x 3.5” SAS/SATA HDD max 64TB
Rear drive bays: Up to 2 x 2.5” SAS/SATA (HDD/SSD), NVMe SSD max 15.36TB
Optional DVD-ROM, DVD+RW |
| Power supplies | 495W Platinum
750W Platinum
750W 240HVDC Platinum*
1100W 48VDC
1100W Platinum
1100W 380HVDC Platinum* | 1600W Platinum
750W Titanium
Hot plug power supplies with full redundancy option
Up to 8 hot plugs fans with full redundancy
*Available in China and Japan only |
| Dimensions | Form factor: Rack (1U) | Height: 42.8mm (1.69”)
Width*: 482.0mm (18.98”)
Depth*: 808.5mm (31.8”)
Weight: 21.9kg (48.3 lbs.)
*Dimensions include bezel. |
| Embedded management | iDRAC9, iDRAC Direct, iDRAC RESTful API with Redfish, Quick Sync 2 wireless module (optional) |
| Bezel | Optional LCD bezel or security bezel |
| OpenManage™ Software | OpenManage Enterprise
OpenManage Mobile | OpenManage Power Center |
Integrations and
connections | Integrations:
Microsoft® System Center
VMware® vCenter™
BMC Truesight
Red Hat Ansible Modules | Connections:
IBM Tivoli® Netcool/OMNIbus
IBM Tivoli® Network Manager IP Edition
Micro Focus® Operations Manager I
Nagios® Core
Nagios® XI |
| Security | TPM 1.2/2.0, TCM 2.0 optional
Cryptographically signed firmware
Secure Boot | Silicon Root of Trust
Secure erase
System Lockdown (requires iDRAC Enterprise or Datacenter) |
| I/O & Ports | Network Options: 4 x 1GbE
2 x 10GbE + 2 x 1GbE
4 x 10GbE
2 x 25GbE
Front Ports: 1 x Dedicated iDRAC direct USB
1 x USB 2.0
1 x USB 3.0 (optional)
1 x Video | Rear Ports: 1 x Dedicated iDRAC network port
1 x Serial
2 x USB 3.0
1 x Video
PCIe: 3 x Gen3 slots all x16
Video Card: 2 x VGA |
| Accelerator options | Up to 3 single-width GPU (NVIDIA T4) or up to 1 FPGA | See /GPU for latest information. |
Supported operating
systems | Canonical® Ubuntu® LTS
Citrix® Hypervisor
Microsoft Windows Server® LTSC with Hyper-V
Oracle® Linux | Red Hat® Enterprise Linux
SUSE® Linux Enterprise Server
VMware® ESXi |
Front view and features
Figure 1. Front view 4 x 3.5-inch drive chassis
Figure 2. Front view 8 x 2.5-inch drive chassis
Figure 3. Front view 10 x 2.5-inch drive chassis
Back view of the system
The back panel of a PowerEdge system contains access to I/O connectors for both embedded and add-in devices, including networking, video, serial, USB, system ID, and system management access ports. Most add-in PCI cards are accessible through the back panel. It is also the default location for power supply units (PSU), including the points for AC/DC connections.
Depending on your system configuration, the drive backplanes supported in PowerEdge R640 are listed here:
● 2.5 inch (x8) SAS, SATA, or NVMe backplane
● 2.5 inch (x10) SAS, SATA, or NVMe backplane
● 2.5 inch (x10) SAS, SATA, or NVMe backplane and 2.5 inch (x2) SAS or SATA backplane (back)
● 3.5 inch (x4) SAS or SATA backplane
Figure 4. Back panel view of 2 x 2.5 inch hard drives with 1 PCIe expansion slot
Figure 5. Back panel view of system with 3 PCIe expansion slots
Figure 6. Back panel view of system with 2 PCIe expansion slots
