| US$5,000.00-10,000.00 | 1 Piece (MOQ) |
| SPECIFICATION | Z3032X10/1 Z3040X10/1 | Z3040X13/1 | |||
| Max. drilling capacity | mm | 32/40 | 40 | ||
| distance spindle axis to column generating line | mm | 300-1000 | 300-1300 | ||
| diameter of column | mm | 240 | 300 | ||
| Spindle taper | MT4 | MT4 | |||
| Spindle travel | mm | 280 | 280 | ||
| Spindle speeds range | r/min | 32-2500 | 32-2500 | ||
| Spindle speeds series | 16 | 16 | |||
| Range of spindle feeds | mm/r | 0.10-1.25 | 0.10-1.25 | ||
| Spindle feeds | 8 | 8 | |||
| Distance spindle nose to working surface of base | mm | 220-1000 | 300-1320 | ||
| Dimension of worktable | mm | 600*450*450 | 600*450*450 | ||
| Dimension of base | mm | 1710*800*160 | 2050*900*200 | ||
| Overall size | Mm | 1760*800*2050 | 2100*900*2300 | ||
| Power of main motor | Kw | 2.2 | 3 | ||
| G.W/ N.W | kg | 1920/1830 | 2500/2100 | ||
| Packing dimension | cm | 187*97*220 | 235*106*245 | ||
| STANDARD ACCESSORIES | OPTIONAL ACCESSORIES | ||||
| Box shape worktable Taper Sleeve Tool releasing wrench Drift Eyelet bolts | Quick change chuck Tapping Chuck Grease Gun | ||||
