Waste Pet Bottle Flakes Granulating Machine

Product Description

PET bottle/flakes Granulating/Pelletizing Line/Extruder
1. Screw components designed by computer aids is kneading type, has excellent self-cleaning function,
the new kneading block design effectively avoid the problems of overheating and energy consumption.
2. According to process system and formula requirements, the unit can optimize its L/D ratio, barrel structure,
screw array, venting number and location, feeding method, electrical control methods etc. for rational
allocation.
3. Granulation system: water-cooling strand pelletizing, air-cooling die face hot cutting
water ring die face hot cutting, Eccentric water mist hot cutting, water and underwater die face hot cutting and so on.

Technical data:

Model	Screw Diameter D (mm)	Screw L/D	screw speed N (r/min)	Main motor power P(KW)	Screw Torque T (N.m)	Torque Level T/N³	Capacity Q(kg/h)
SHJ20	21.7	28~40	600	3/4	30	4.8	3-15
SHJ35	35.5	28~56	500	11 / 15	115	4.2	20-70
SHJ50	50.5	28~56	500	45 / 55 / 75	425	5.1	80-150
SHJ52B	51.4	28~56	400/500/600/800	45 / 55 / 75	425	5.1	120-280
SHJ65	62.4	28~56	500 / 600	55 / 75 / 90	675	4.8	150-250
SHJ65B	62.4	28~56	400/500/600/800	90/110	675	4.8	200-500
SHJ75	71	28~56	500 / 600	90 /110 /132	1005	4.6	250-350
SHJ75B	71	28~56	400/500/600/800	110 /132/180	1005	4.6	300-700
SHJ95	93	28~56	400 / 500	250 / 315	2815	5.9	600-1000

Detailed image

FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.

Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 45-60 days if the goods are not in stock, it is according to what kind of machine you need

Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?
A: 30% T/T in advance ,70% balance before shipment or Negotiable
If you have another question, please feel free to contact us as below
Our serives
We will test machines in our factory before delivery. Customer check machines running in our factory, after customer is fully satisfied with the quality, then delivery, when machines arrive in customer's factory, we will send our engineer to test the machine in customer's factory
We supply machines technical support, material formulation; guarantee machines and spare parts supply
Contact us
Company name: Zhangjiagang Camel Machinery Co.,ltd
Address: Yongli Economic development zone, LeYu town, Zhangjiagang city, Jiangsu province, China
Tel: +86-512-58539862 Fax: +86 -512-58539863
Mobile/whatsapp/: 0086 13222230431

Website: camelmachinery.en.made-in-china.com

---
