Advanced Shotcrete Sprayer for Efficient Concrete Application - Lanhi Lhp400f

Product Description

Product Description
The LHP40F The wheeled wet spray manipulator is a state-of-the-art solution designed by integrating the best domestic and international wet spray machine technologies. This next-generation equipment boasts a meticulously optimized structure, ensuring a remarkably low failure rate. The high versatility of accessories and consumables combined with low operating costs makes it a standout in its class. Key features include an impressive spray capacity, superior blockage resistance, minimal rebound effect, and reliable operation, all of which significantly boost construction productivity and reduce concrete usage.
Achieving a maximum spray volume of up to 40m³/h, this manipulator offers exceptional spraying efficiency and blockage-resistant pipes for seamless operation.
Equipped with a diesel-electric dual power system, this machine guarantees rapid construction progress, enabling projects to advance swiftly.
Featuring dual quick-setting agent tanks with a substantial capacity of 1.5 cubic meters, this machine is perfectly suited for large section constructions.
With a compact footprint, excellent flexibility, and easy site accessibility, this equipment is designed for smooth entry and exit from construction sites.
The high versatility of accessories and consumables ensures low operating costs, making it an economical choice for large-scale projects.
Product Parameters

Transport dimensions (L × W × H)	8340×2700×3250mm
Total weight	16t
Engine power	103kW
Installed electrical power	75kW
Operating mode	Electric construction + diesel-powered emergency
Control mode	Wireless remote control
Operating voltage	380V
Operating range (width × height)	26×15m
Chassis form	Operating chassis
Driving mode	One-way driving
Driving and steering methods	Four-wheel drive, front-wheel steering
Minimum ground clearance	420mm
Maximum grade	29%
Turning radius	10m (two wheels)
Maximum speed	15km/h
Approach angle/departure angle	16°/16°
Maximum spraying volume	40m³/h
Maximum particle size for spray aggregate	25mm
Hopper capacity	0.3m³
Capacity of quick-setting agent tank	1.5m³
Form of quick-setting agent pump	Squeeze pump
Discharge volume	/
Discharge pressure	/

Detailed Photos
FAQ
1,What can you buy from us?
Our current main products include comprehensive solutions for underground engineering machinery and intelligent mining equipment. This includes tunnel boring machines, integrated arch anchoring and spraying trolleys, arch anchoring trolleys, integrated arch drilling trolleys, arch frame installation trolleys, wet spraying rigs, and rock drilling rigs. We have the capacity to provide customers with integrated total solution services.
2,What about the MOQ?
The Minimum Order Quantity (MOQ) is 1 set.
3,What payment terms do you accept?
We accept T/T with a 50% prepayment.
4,What about the order lead time?
The usual lead time is 15 days.
5,What logistics methods can you use for shipment?
Truck delivery can be arranged in Central Asia and Russia, and you can also choose rail and sea shipping.
6,How is your delivery time?
The delivery time via China-Europe trains is 15 to 20 days, while sea shipping takes approximately 2 to 3 months.
7,How about your customer service and after-sales service?
We offer 24/7 online support and provide after-sales support in Russia and Central Asia.

---
