28kHz 68kHz 1800W Double Frequency Digital High Efficient Ultrasonic Cleaning Machine

Product Description

1. Dual-Frequency
2 frequencies can be switched easily as you need. For different cleaning process, you can choose different frequency, and it is also
very suitable for workpiece which needs both coarse and fine cleaning.
2. Automatic Sweep
Sweep can eliminate the standing waves effectively. That's helpful to improve ultrasonic distribution in the tank and make cleaning moreuniformly.
3. 2 Times Peak Power
2 times peak power excitation can act on stubborn stains and semi-aqueous solvents, ultrasonic performance is improved obviously.
4. Linearly Adjustable Power
Ultrasonic power can be adjusted 10-100% linearly, which is more precisely for different cleaning request.
5. Load Self-Adaption
It will adjust itself to fit to different working conditions (liquid temperature, liquid level and with/without workpiece) automatically, and maintainthe optimal working frequency and constant power output.
6. High Definition Industrial Level LCD Display
User-friendly LCD display allows user to monitor working status and set parameters.
7. Efficient Cleaning
Adopting peak modulation technology which can breakdown the bubbles more quickly and remove the stubborn stains easily. Under samecondition, the breakdown speed of foil is significantly improved.
8. Stable Output
Self-adaption technology can ensure the machine to fit to load changing perfectly, such as different liquid level, liquid temperature changing and workpiece movement. Ultrasonic performance will keep still.
9. High Conversion Efficiency
The conversion efficiency of ultrasonic and electric energy is more than 95%. The energy conversion is more than others at same ultrasonic power output.
10. Extended Function
Circulation system, oil skimmer, bubbling tank, rinsing tank, high pressure spraying tank and drying tank etc can be extended as your d emands.

Name	Dual-Frequency Ultrasonic Cleaner
Model	RM85	RM120	RM160	RM210	RM520
Capacity	85L	120L	160L	210L	520L
Ultrasonic Frequency	25/45kHz, 28/68kHz, 40/80kHz, 40/130kHz, 80/130kHz
Ultrasonic Power	1500W	1800Watts	2400Watts	4000Watts	6000Watts
Power Adjustment	10-100%
Heating Power	5KW	6KW	8KW	10KW	10KW
Heating Temperature	30-80°C
Timing	0-60min. or ∞
Inner Tank Size	600x400x350mm	650x450x400mm	700x500x450mm	680x620x500mm	2100x450x530mm
Basket Size	510x330x180mm	560x380x230mm	600x425x260mm	580x580x400mm	2000x350x300mm
Overall Size	700x600x800mm	750x650x800mm	880x700x850mm	780x820x850mm	2260x785x900mm
Tank Material	SUS304 or SUS316L
Power Supply	220V/50Hz, 1 Phase		380V/50Hz, 3 Phase
Power Cable Length	3m
SUS Cover	√
Rolling Wheel	√
Circulation System	optional
Oil SKimmer	optional

1. Are you manufacturer or trading company?
We are manufacturer. All the core components (ultrasonic transducer, ultrasonic generator) are home-made by ourselves.
2. Do you accept OEM and ODM?
Yes, we also have profession R&D teams (ultrasonic transducer team, ultrasonic generator team and mechanical design team) to responds your special needs
quickly.
3. Delivery time Standard products can be delivered within 7 working days. Customized machine depend on the design.
4. Warranty We guarantee quality of the products for a period of 1 year. If any quality problem within warranty, we'll provide free spare parts or repairing service.
5. Do you provide trial cleaning service?
Yes, you're welcome to send the workpieces for trial cleaning. We'll send you video and report about the test. It's free service. 6. Can you provide ultrasonic transducer or generator if any failure?
Yes, ultrasonic transducer and ultrasonic generator are designed and manufactured by ourselves. We can send the right parts quickly for replacement.
7. Payment Methods?
T/T, L/C, D/P, D/A, West Union, Paypal, MoneyGram, Escrow.
8. Which frequency and power is suitable for our workpiece?
Please contact us and provide details as specific as you can. Information includes: the size, material, weight and dirt of your
workpiece and cleaning tank dimension etc.

---
