| US$4,400.00-8,900.00 | 1 Piece (MOQ) |
| Model | BK-FD20S(Standard) | BK-FD20T(Stoppering) | BK-FD30S(Standard) | BK-FD30T(Stoppering) | |
| Freeze Drying Area | 0.3m² | 0.2m² | 0.4m² | 0.3m² | |
| Shelf Temperature | -50ºC~+70ºC(no-loading) | ||||
| Cold Trap Temperature | <-80ºC(no-loading) | ||||
| Vacuum Degree | ≤1Pa(no-loading) | ||||
| Water Capture Capacity | ≥6 | ≥8 | |||
| Cold Trap Volume | 14L | / | 26L | ||
| Cold Trap Size(Diameter*H) | Φ200*460mm | / | Φ320*520mm | ||
| Drying Chamber Size(W*D*H) | 330*325*470mm | 340*500*420mm | 480*380*540mm | ||
| Shelf&Tray Size(W*D*H) | Shelf: 400*270*18mm Tray: 395*265*25mm | Shelf: 300*340*18mm Tray: 295*335*25mm | |||
| Qty. of Shelf&Tray | Shelf: 3+1; Tray: 3 | Shelf: 2+1; Tray: 2 | Shelf: 4+1; Tray: 4 | Shelf: 3+1; Tray: 3 | |
| Sample Loading Capacity(Liquid) | 3L | 2L | 4L | 3L | |
| Height Between Trays | 70mm | 100mm | 50mm | 70mm | |
| Tray Temperature Difference | ±1ºC | ||||
| Refrigerant | R404A+R23 | ||||
| Condenser Cooling Mode | Air cooling | ||||
| Defrost Mode | Electric defrosting | Natural defrosting(optional electric defrosting) | Electric defrosting | ||
| Stoppering Mode | / | Automatic | / | Automatic | |
| Total Qty. of Vial | Φ22mm | / | 440 | / | 654 |
| Φ16mm | / | 868 | / | 1200 | |
| Φ12mm | / | 1554 | / | 2187 | |
| Vacuum Pump | 4L/S(14.4m³/h) | 6L/S(22m³/h) | |||
| Electric Defrosting Consumption | 800W | 800W | / | 1000W | |
| Silicone Oil Heating Rods Consumption | 800W | 800W | 1000W | 1000W | |
| Hydraulic Pressure Station Consumption | / | 500W | / | 1000W | |
| Total Consumption | 3KW | 4KW | 4.5KW | 5.5KW | |
| Power Supply | AC220V, 50Hz/60Hz(single phase) | ||||
| Main Body Weight | 300kg | 400kg | |||
| External Size(W*D*H) | 1033*781*1580mm | 928*825*1366mm | 1272*853*1679mm | ||
| Packing Size(W*D*H)/ Gross Weight | Main Body | 1150*900*1780mm/400kg | 1150*900*1905mm/400kg | 1050*945*1570mm/450kg | 1392*995*1880mm/651kg |
| Vacuum Pump | 950*420*500mm(37kg) | 790*340*460mm(57kg) | 790*300*470(52kg) | ||
