Product Description
Product Description
1.Parameters:
Max size of paper:360mm×520mm
Min size of paper:210mm×297mm
Max printing area:340mm×505mm
Thickness of paper:0.04~0.4mm
Printing plate size:400×510×0.15
Rubber blanket size:450×510×1.9
Size of mackintosh soffit-lining:380×510×1.05
Size of cashmere:Φ50×600mm
Printing feeding:8~10mm
printing speed:3000~10000P/h
Weight for paper feeding:75Kg
Height for paper feeding:400mm
Power:4Kw(380V three-phase))
Weight:2800Kg
Dimension;1537×1470×1560
Noise:<80db(A)
2.Description:
High-precision components of the helical gear drive system, high-precision rolling bearing, coupled with intelligent lubrication walk shoulder-iron drum, the printing pressure to ensure stability and smooth running.
Rubber rollers used pneumatic pressure on-off, three-point suspension. Pneumatic on-off pneumatic-off ink water, electric adjustment of the ink, simplified operation, reduced the fault.
Express Edition folder, the plate in the operation of X to Y to the fine-tuning, reducing the adjusted version of the technical requirements, to reduce the tune version of the print runs and improved yield.
The most classic of the paper to the agency, Fei da, friction with feeding, easy-to-use and reliable.
3.Company strength:
1.15 years factory experience
2.10 years export experience
3.Over one hundred professional factory workers
4.100% quality guarantee,supply all kinds of certificates
5.Good after-sales serive,we send engineers to repair machine overseas.
6.Primary products:
Automatic High Speed Flute Laminater
ZXSCM Book Case Making Machine
650UV Coating Machine
ZX-650C Manual Paper Pasting Machine
Box Making Machine
Hot Melt Gluing Machine and Gluing Machine
Table Gluing Machine
Paper Pressing Machine.etc
7.Following is our factory pictures:
4.Certificate:
5.Trade show:
6.Packaging & Loading:
Welcome to visit our factory!
>>
