| US$38,000.00-40,000.00 | 1 Piece (MOQ) |
| Model | units | X718 |
| Table size | mm | 2800x500 |
| Table travel(X,Y) | mm | 2500x1020 |
| Distance from spindle to table surface | mm | 385-1540 |
| Distance from spindle to table surface | mm | 0-1160 |
| Distance spindle to table surface | mm | 0-1090 |
| Number/width/distance of T-slot | mm | 4-20-100 |
| Max.load of table | kg | 5000 |
| Feed speed | mm/min | 22.4-560 |
| Rapid feed speed | mm/min | 1650 |
| Z axes feeding | mm/min | 11.2-280 |
| Z speech axes feeding | mm/min | 825 |
| Spindle taper | 7:24 ISO50 | |
| Spindle speed range | rpm | 36-1340 |
| Spindle speed step | steps | 12 |
| Distance from spindle axis to column | mm | 900 |
| Spindle motor power | kw | 7.5 |
| Overall dimension | mm | 3020×3000×3000 |
| Machine weighe | kg | 9000 |
