Feedback form of production line user demand information
| serial number | project | content | remarks |
| one | Thickness range of strip material | | |
| 2 | Width range of strip material | | |
| three | Uncoiled material | | |
| four | Plate yield limit | | |
| five | Weight of uncoiled coil | | |
| six | Inner diameter of uncoiling coil | | |
| seven | Maximum outer diameter of uncoiling coil | | |
| eight | Leveling accuracy of production line | | |
| nine | Line speed | | |
| 10 | Leveler requirements | Simple and smooth | | |
| Double leveling | |
| Does the leveler require a monotonic structure | |
| Leveling roller material | |
| Are there any special requirements for roller diameter and number | |
| 11 | Plate shearing machine form | Hydraulic brake type plate shearing machine | | |
| Sheet flying shear | |
| Thin plate high-speed mechanical shear | |
| Tracking shears | |
| Other requirements | |
| 12 | Is palletizing required | No palletizing | | |
| Ordinary palletizing | | |
| Lifting palletizing | | |
| Pneumatic turnover palletizing | | |
| 13 | Is longitudinal shear required | No longitudinal shear | | |
| Number of longitudinal shears | |
| Minimum width of longitudinal shear | |
| Longitudinal shear width tolerance | |
| Longitudinal shear straightness requirements | |
| 14 | Is rewinding required | No rewinding | | |
| Winding inside diameter | |
| Winding weight | |
| Maximum and minimum diameters of winding | |
| Selection of several process routes for production line (equipment can be deleted or added according to user's requirements) |
| 15 | Steel coil saddle → feeding trolley → uncoiling → feeding machine → leveling machine → length measuring device → tail plate clamping → plate shearing machine → conveying roller table → feeding machine → palletizing | | Single leveling shearing production line |
| 16 | Steel coil saddle → feeding trolley → uncoiling → feeding machine → leveling machine → looper → finishing machine → length measuring device → tailboard clamping → plate shearing machine → conveying roller table → feeding machine → palletizing | | Double leveling shearing production line |
| 17 | Steel coil saddle → reeling trolley → uncoiling → feeding machine → leveling machine → trimming shearing plate → looper → centering → slitter → waste edge reeling → looper → pre-splitting → tension unit → reeling machine → unloading trolley → unloading saddle | | Longitudinal shear winding production line |
| 18 | Steel coil saddle → coiling trolley → uncoiling → feeding machine → leveling machine → looper → centering and feeding → slitting machine → waste edge coiling → looper → sizing machine → length measuring device → plate shearing machine → lifting roller table | | Vertical and horizontal shearing production line |
| 19 | Steel coil saddle → reeling trolley → uncoiling → feeding machine → leveling machine → looper → centering and clamping → slitting machine → waste edge reeling → looper → pre-splitting → tension unit → reeling machine → unloading trolley → unloading saddle → telescopic transition roller table → centering and separation → sizing machine → length measuring device → shearing machine → lifting roller table | | Longitudinal shear winding and transverse shear composite production line |
| 20 | Steel coil saddle → coiling trolley → uncoiling → feeding machine → leveling machine → looper → centering and clamping → trimming machine → waste edge coiling → looper → sizing machine → length measuring device → plate shearing machine → conveying roller table → throwing machine → palletizing | | Trimming cut to length line |
| 21 | Other special requirements | | |
