US$10,000.00-30,000.00
|
1 Set
(MOQ)
|
Basic Info.
Material Processed
PP Melt-Blown Fabric
Computerized
Computerized
Certification
ISO9001:2008, CE
Stage
Single/Double Stage Pelletizing Machine
Degassing
Vacuum Degassing
Granules Cut
Die Face Cutting
Type
Granulating Production Line
Raw Material
PP PE Film,Bag ,Bottle Flakes,etc
Function
Make Recycle Plastic Granules
Product Name
PP PE Pelletizing Machine
Machine Type
Single or Double Stage Pelletizing
Transport Package
Container
Specification
200kg/h-1000kg/h
Production Capacity
100 Sets Per Year
Packaging & Delivery
Package Size
1500.00cm * 500.00cm * 350.00cm
Package Gross Weight
12000.000kg
Product Description
PE PP film woven bags compacting pellets maker/PE PP film woven bags granules maker/compacting extruder pelletizing line
Product Description
Application:
PE, PP LLDPE LDPE HDPE film, PP Silk, Flakes (≤0.5mm), Bags, etc.
Note, our RCDJ series compactor granulator can be pull strip cutting method, or water ring cutting method for option
PS/EPE/XPS/EPS Foam Sheet Board Block Agglomeration Recycling Granulating Pelletizing Plant Consists of:
Belt conveyor(metal detector) → Compactor → Main extruder(vacuum degassing system) → Hydraulic screen changer → Sub- extruder → Hydraulic screen changer → Water ring cutting system →Dewatering machine → Air blow system → Storage hopper → control cabinet.
Detailed Photos
Product Parameters
| Model | Data of compactor | Data of single screw extruder | Throughput rate(Kg/hr) |
Efficiency volume (Liter) | Motor power (KW) | Diameter of screw(mm) | L/D | Motor power(KW) |
| RCDJ85 | 300 | 37 | 85 | 33 | 55 | 160-220 |
| RCDJ100 | 500 | 55 | 100 | 33 | 90 | 280-360 |
| RCDJ130 | 800 | 75 | 130 | 33 | 132 | 450-550 |
| RCDJ160 | 1000 | 110 | 160 | 30 | 185 | 650-750 |
| RCDJ180 | 1200 | 132 | 180 | 28 | 250 | 800-1000 |
Certifications
Packaging & Shipping
Exhibition
Features
Advantages:
1. Our RCSJ series PE PP Film Double Stage Pelleting Line/Plastic Granules Making Machine/Production Plant compactor pelletizing line has pull strip cutting, and water ring cutting method(include vertical water ring cutting and horizontal water ring cutting) for option.
2. The machine with high efficiency, working stable, large capacity etc.
3. World famous brand components applied on the production line- bearing, teco contactor, Japan Omron temperature controller, ABB or TECO invertor, Siemens motor, and Siemens PLC control.
4. The whole production line with CE certification, ISO9001 certification.
>>
