Accurate Concrete Floor Leveling Screed with 6m Boom 3m Screed Head Laser Screed

Product Description

Boom Laser screed RWJP32
The Laser Screed is the pinnacle of precision in large area concrete construction, ideal for modern industrial workshops, expansive markets, spacious storage facilities, bustling airports, grand plazas, and more. It expertly meets the stringent construction demands for vast areas, delivering unmatched accuracy and exceptional performance. planeness and levelness. Detailed Photos

	machine can rotate 360°, specially designed soft start and stop. screed head can swing +-45°.
Hydraulic supporting legs, one-key leveling		4 Hydraulic drive motor,solid tyre, puncture proof,
	The machine can rotate 360°, specially designed soft start and stop. Specially designed auger, the dynamic balance is excellent, improved the leveling accuracy

Product Parameters

Model	RWJP32
Type	Boom type
Engine
Model	YANMAR
Type	Diesel Engine, Liquid cooled, 4 stroke, 4 cylinder
Power	35kW/3000rpm
Engine oil volume	6.0L
Fuel consumption	261g/kwh
Running device
Driving	4 Hydraulic drive motor
Wheel	Antiskid tyre
Steering	Front Wheel/ 4-Wheel/ Crab-shaped turn
Outrigger	4 legs, Self-leveling
Working Speed	20M2/min
Driving Speed	0-6km/h
Screed head
Type	Self-leveling
Arm Length	6000mm
Width	3000mm
Paving type	With auger
Auger force	Hydraulic motor
Exciting force	3000N
Vibration frequency	60Hz
Swing Angle	±45°
Screed head control	Ratio control
Height of screed head	500mm
Control accuracy	±1.5mm
Laser control system
Control type	Microcomputer laser scan
Control effect	Flat, slope or double slope
Operation mode
Chair position	Ride-on forward type
Forward and reverse	Hand control, stepless speed walking
Telescopic arm	Hand control, stepless speed
Steering	Steering wheel
Cleaning system
Power	Hydraulic motor
Theoretical flow	20L/min
The Max pressure of inlet	0.5Mpa
Rated pressure	7MPa
Fuel Volume	100L
Size and Weight
Outside size(Working)	4500×3500×2500mm
Weight	6000kg

FAQ

1.Does your product support customization? Can I put my logo on the product?
Yes,we support customization, labeling and color change.
2.What is the packaging of the product?
Smokeless plywood.
3.What certificates does the product have?
CE,ISO9011.
4.What is the minimum order quantity?
1 unit.
5.What information do I need to provide for a quotation? Do you have a product quotation sheet?
Leave your contact information and we will contact you ,send you our quotation.
6.How long does the delivery time usually take?
Usually is 15-30days.
7.Does your company provide after-sales service?
2 years warranty,If there are quality problems with the accessories during the warranty period, we will replace them free of charge. We are not responsible for any human caused issues.
