| US$1,088.00-1,395.00 | 3 Sets (MOQ) |
| Specification | |
| Model No. | KY450/KY700 |
| Height of center | 125mm |
| Max.distance between two centers | 450(700)mm |
| Max.length cutting | 420(660)mm |
| Max.swing over bed | 250mm |
| Max.swing over carriage | 130mm |
| Taper of spindle nose | MT4/27mm |
| Spindle speed range | 115-1620rpm |
| Matric thread cutting | 0.2-3.5mm(20 kinds) |
| Inch thread cutting | 8-56/1(20 kinds) |
| Moulder thread cutting | 0.1-1.25mm(10kinds) |
| Range of longitudinal feed | 0.05-0.1mm |
| Max.round angle of tool post | 45° |
| Max.travel of tool post | 70mm |
| Taper of tailstock sleeve | MT2 |
| Motor | 0.75kw |
| Drilling/Milling | |
| Spindle taper | MT3 |
| Spindle stroke | 80mm |
| Spindle nose to table | 160mm |
| Milling table size | 215*150mm |
| Spindle speed | 400-1640rpm |
| Motor poser | 550W |
| Standard accessories | |
| Splash guard | 1 pc |
| Chip tray | 1 pc |
| Drawbar | 1 pc |
| Arbor | 1 pc |
| Toolbox & tools | 1 set |
| Optional accessories | |
| 4-jaw chuck | 1 set |
| Backplate | 1 pc |
| Follow rest | 1 pc |
| Steady rest | 1 pc |
| Face plate | 1 pc |
| Collet chuck | 1 set |
| Turning tools | 1 pc |
