High Efficiency Pet Pellets Plastic Sheet Extrusion Machine

Product Description

Product Description
Twin-Screw Extruder by Dongguan Taizhang Machinery Co., Ltd.
What is a Twin-screw Extruder? The twin-screw extruder, developed by Dongguan Taizhang Machinery Co., Ltd., is a cutting-edge plastic processing equipment that surpasses single-screw extruders in performance and efficiency.
Main Features:
Good feeding, mixing, and plasticizing performance
Efficient exhaust and extrusion stability
Comprehensive systems including screw, feeding, heating, cooling, hydraulic screen changing, vacuum, and electronic control
Screw System: The core of the twin-screw extruder, featuring sections for feeding, melting, mixing, exhaust, and homogenization. Customizable threaded elements cater to various production requirements.
Advantages:
Efficient production with higher efficiency
Wide application range for various materials
Uniform mixing for consistent product quality
High precision for stable product quality
Easy-to-use control system with minimal maintenanc

In conclusion, the twin-screw extruder by Dongguan Taizhang Machinery Co., Ltd. offers superior production efficiency, versatile application, uniform mixing, and high precision, making it a valuable asset in various industries.
Project Overview:

1. Conditions of Use:	380V/3P/50Hz
2. Production material:	PET pellets and regularly broken pieces
3. Product specifications:	thickness:δ=0.15-1.5mm;Finished product width:800mm
4. Extrusion output:	300-400Kg/h

Equipment List:

1. 75/40 parallel twin screw extruder	1 set
2. Hydraulic screen changer	1 set
3. Melt metering pump	1 set
4. Mold	1 set
5. Three-roller calender	1 set
6. Roller temperature control system	1 set
7. Cooling shaping bracket	1 set
8. Waste edge trimming device + waste edge winding device (both sides)	1 set
9. Silicone oil coating device with dryer (double-sided)	1 set
10.Traction device	1 set
11. Dual station winding machine	1 set
12. Electrical control system	1 set

Dongguan Taizhang Machinery Co., Ltd. presents the Pet Twin Screw Extruder Line, designed for high-performance plastic sheet production. Elevate your manufacturing efficiency with this cutting-edge equipment that ensures precision and quality output.

Warehouse/workshop	Machine size: approximately 30m (length) × 6m (width) × 3.5m (height) construction of foundations, building works, earthworks and wall works. Supply of cranes, forklifts or other lifting equipment; erection materials and tools.
Temperature / Humidity	≤50ºC/≤95%
Power supply	Three-phase,380V,50 Hz
Wires/cables/water pipes	Wires/cables from the power supply to the control cabinet of this production line; all cables from the control cabinet to each machine. Water pipes: provide water to machines and pools.
Cooling water	No dissolved or suspended minerals such as phosphorus, sulfur, and iron. Inlet water temperature T1: maximum 15ºC; outlet temperature T2: T2=T1+5ºC; hardness: 5-8odH;
lubricating oil	Exxon Mobil
Compressor	Supply compressed air

Energy consumption

Installed power	About 250KW (actual power consumption percentage: 70%)
Cooling water	~1.5M3/hr, ≤30ºC, ≥0.3Mpa
Compressed air	1.5/m3/min, 0.5~0.8Mpa
Production staff	1 person

Welcome to Dongguan Taizhang Machinery Co., Ltd. Product: Auxiliary Facilities for Equipment Installation Features:
Includes foundation installation drawings for easy setup
Requires preparation of water, electricity, and gas lines as per installation drawings
All materials needed for production must be prepared in advance
One-year warranty on equipment (excluding wearing parts and human factors)
Life-time paid services available
Remark: The demander is responsible for preparing auxiliary facilities and materials as per provided installation drawings.

---
