China Hot Selling Double Column Fixed-Beam Gantry Machining Center Aluminum Alloy Machining

US$28,000.00
1 Piece
US$18,000.00
2+ Pieces

Basic Info.

Model NO.
GMC1614
Application
Metal
Process Usage
Metal-Cutting CNC Machine Tools
Movement Method
Contour Control
Control Method
Closed-Loop Control
Numerical Control
CNC/MNC
Processing Precision
0.01~0.02(mm)
Performance Classification
Economical CNC Machine Tools
Certification
CE
Condition
New
Spindle Taper
Bt40
Spindle Motor
11/15kw
System
Syntec/Mitsubishi/Fanuc/Siemens
Max Load
5000kg
Name
High Speed Gantry Machining Center
X/Y/Z Speed
24/24/24 M/Min
Tool Alignment
Auto Tool Checking
Working Table
1800*1200
Precision
+-0.01~0.02mm
Repeat Precision
+-0.009mm
Power
5.5kw 380V 3 Phase
Spindle Speed
12000 Rpm
Max Working Speed
6m/ Min
Applicable Industries
Machinery Repair Shops, Manufacturing Plant, Mold
Type
4 Axis CNC Machine
Transport Package
Sea Worthy Plywood Case
Specification
5400*3700*3900
Trademark
WT
Origin
Dongguan City China Prc
HS Code
8459619000
Production Capacity
2000PCS/Year

Product Description

GMC1614 China Hot Selling Double Column Fixed-beam Gantry Machining Center Aluminum Alloy Machining
Product Description
A mobile gantry machining center machine tool, suitable for machining equipment for various large workpieces in aerospace, shipbuilding, power generation, construction machinery, locomotives, machine tools, textile machinery, printing machinery, molds and other industries. The high-strength, high-rigidity design of the machine tool and the structure of the large-flow shoulder channel have the characteristics of high precision, high efficiency, flexibility, and environmental protection.
Product Paramenters
Item Unit GMC-1614 GMC-1816 GMC-2014 GMC-2515 GMC-3018
Journey
Three-axis travel (X/Y/Z) mm 1600/1600/750 1800/1800/800 2000/1600/750 2500/1700/800 3000/2000/800
Distance from spindle nose to work table mm 250-1000 200-1000 250-1000 200-1000 200-1000
distance between two columns mm 1400 1600 1400 1500 1800
Workbench
Table size (length X width) mm 1800X1200 2000X1400 2200X1200 2700X1300 3100X1700
Maximum load kg 5000 6300 6000 7500 9500
Number of T-slots X Slot Width X Spacing 7X22X180 9X22X160 7X22X180 7X22X170 9/22/180
Spindle
Spindle speed rpm 12000 6000 12000 6000 6000
Spindle taper hole BT40 BT50 BT40 BT50 BT50
Spindle motor power kw 11/15 15/18.5 11/15 15/18.5 15/18.5
Spindle maximum output torque Nm 52.5/118 143/236 52.5/118 143/236 143/236
Speed
Rapid traverse speed (X/Y/Z axis) m/min 24/24/24 24/24/12 24/24/24 24/24/12 12/24/12
Cutting feed rate m/min 10/10/10 10/10/10 10/10/10 10/10/10 10/10/10
Tool magazine
Number of tools pcs 24 24 24 24 24
Tool diameter/length/weight Ф75mm/300mm/7kg Ф112mm/350mm/15kg Ф75mm/300mm/7kg Ф112mm/350mm/15kg Ф112mm/350mm/15kg
The maximum diameter of the tool (full knife / adjacent empty knife) mm 75/150 112/200 75/150 112/200 112/200
Machine tool accuracy
Positioning accuracy (X/Y/Z) mm 0.020/0.020/0.012 0.020/0.020/0.015 0.020/0.020/0.012 0.025/0.020/0.015 0.025/0.020/0.015
Repeated positioning accuracy (X/Y/Z) mm 0.009/0.009/0.008 0.009/0.009/0.008 0.009/0.009/0.008 0.012/0.009/0.008 0.012/0.009/0.008
Other
Air source/air pressure 280L/min6-8bar 280L/min6-8bar 280L/min6-8bar 280L/min6-8bar 280L/min6-8bar
Total capacity of machine tools KVA 35 45 35 45 45
Tank volume L 370 370 370 420 450
Machine tool dimensions (X/Y/Z) mm 5400X3700X3900 5800X3900X4500 2800/3700/3900 7000X3900X4500 8200X4100X4500
Machine Weight (Approx.) kg 13000 14500 15000 24500 28000
