| US$9,572.00 | 1 Piece (MOQ) |
| Description | Unit | SGA3063AH | SGA3063AHR | SGA3063AHD |
| (×) Maximum grinding range (L×W) | mm*mm | 735*340 | 735*340 | 735*340 |
Max.distance from spindle center to table | mm | 580 | 580 | 580 |
| () Maximum load-bearing capacity of the workbench (including suction cups) | Kg | 280 | 280 | 280 |
| (×) Table size(L×W) | mm*mm | 630*300 | 630*300 | 630*300 |
| T Size and quantity of T-shaped slots on the workbench | mm*N | 14*1 | 14*1 | 14*1 |
| Max.longitudinal travel | mm | 710 | 710 | 710 |
| Cross tranal | mm | 340 | 340 | 340 |
| Sucker size | mm*mm | 600*300 | 600*300 | 600*300 |
| :Left and right feed of workbench: | ||||
| Speed | m/min | 7-23 | 7-23 | 7-23 |
| Handwheel per revolution | mm | |||
| :Table transverse movement | ||||
| (mm/) Step feed (mm/time) | 0.5-8 | 0.5-8 | 0.5-8 | |
| continuous feed | mm/min | 0-800 | 0-800 | 0-800 |
| (1/1) Feed of handwheel(1 grid/1 circle) | mm | 0.02/4 | 0.02/4 | 0.02/4 |
| :Wheelhead vertical movement | ||||
| (1/1) Upper and lower handwheel feed (1 grid/1 circle) | mm | 0.01/2 | 0.01/2 | 0.0001/0.001/0.01 |
| (50HZ/60HZ)Spindle up and down movement speed (50HZ/60HZ) | mm/min | hand movement | 460 | 0-460 |
| :Spindle and grinding wheel: | ||||
| Spindle Motor | KW | 5.5 | 5.5 | 5.5 |
| (XX)Grinding wheel (OD×W×ID) Size | mmXmmXmm | 350*30*127 | 350*30*127 | 350*30*127 |
| ()Grinding wheel speed (spindle speed) | rpm | 1400 | 1400 | 1400 |
| Cooling pump motor | KW | 0.09 | 0.09 | 0.09 |
| Hydranlic motor | KW | 2.2 | 2.2 | 2.2 |
| Cross feed motor | KW | 0.06 | 0.06 | 0.06 |
| Left and right feed motor | KW | |||
| Upper and lower feed motor | KW | 0.04 | servo 1.0 | |
| Net weight | Kg | |||
| Gross weight | Kg | 2500 | 2500 | 2500 |
| (××)Package dimensions (L×W×H) | mmXmmXmm | 2350×2220×2150 Based on actual measured dimensions | ||
