China C&C/CIMC 6*4 380HP Concrete Truck

Product Description

China C&C/CIMC 6*4 380HP Concrete Truck

Manufacturer			C&C Trucks
Model			Mixer
Driving Form			6×4
Overall dimension(MM)			9350,9550,9055x2500x3950
Wheelbase			3825+1350,4200+1350
Kerb weight(kg)			14200
GVW(kg)			25000
Engine		Engine Model	YC engine, Cummins engine, Weichai engine
		Horsepower	290-420
		Fuel-injection Systems/Emission	EGR/ Commom rail
		Number of cylinder	6 cylinder in-line water cooling, turbo-charging and intercooling
		Emission standard	Euro-III, Euro-IV
		Engine Brake	Without
Clutch of Radiator Fan			Common Control Silicone Oil Type
Air filter			Common type
Fuel Tank Volume			300L
Clutch Spec.			φ430,pull-type diaphragm
Transmission			FAST, ZF
Front Axle		Load	7500
		Brake type	drum/disk
Drive Axle		Load	26000
		Final reduction ratio	4.11,4.24,4.769,5.26
		Type	LC300
		Brake type	drum/disk
Suspension		Front suspension type	10 pcs of leaf spring
		Rear suspension type	12 pcs of leaf spring
Brake System		Electronic brake	ABS
		Air cylinder	Common type
		Brake Valve Brand	Local brand,Wabco
Frame Spec.(HxWxT) (mm)			300×80×(8+8)
Steering Gearbox			ZF, China brand
Tire Spec.			11.00R20,12.00R20,12R22.5
Max. driving speed			85
Fifth wheel			/
Upper body		dimension	6M3,10M3,12M3
		gearbox	PMP
		motor	PMP
		pump	PMP
Driver's cab		Cab Spec.	Low roof, S2 comfortable style
		Sleeper Quantity	Single
		Front Bumper	High position
		Cab Suspension	Full floating,Cab Suspension: FR /coil spring , RR/coil spring
		Air Conditioner	Manul Control
		Elevating Mechanism of Cab	Electro- hydraulic
		Driver's seat	Airbag shock absorption ,eight-directional regulation,luxury textile fabric
		Co-driver's seat	spring absorption ,Six directional regulation,luxury textile fabric
