| ITEM | UNIT | JT-700HP |
| Workbench | Workbench size | mm | 630*630 |
| Worktable load-bearing capacity | kg | 1200 |
| T-slot width (width x spacing x number of slots) | mm | 22*125*5 |
| Minimum roatation angle | deg | 1 |
| Segmentation accuracy | sec | ±6 |
| Repetitive accuracy | sec | ±2 |
| Trip | X-axis travel | mm | 1080 |
| Y-axis travel | mm | 730 |
| Z-axis travel | mm | 830 |
| Distance from spindle end face to workbench | mm | 180-1010 |
| Distance from spindle center to Z-axis rail surface | mm | 120-850 |
| Principal axis | Speed range | rpm | 8000 |
| Main spindle power (continuous/30 minute rated) | kw | 15/18.5 |
| Spindle torque(rated for continuous/15minutes) | Nm | 143/236 |
| Slope of spindle inner hole | | BT50 |
| Transmission mode | | Belt-type |
| Feed | X-axis rapid displacement | m/min | 20 |
| Y-axis rapid displacement | m/min | 20 |
| Z-axis rapid displacement | m/min | 20 |
| Feed rate | mm/min | 12000 |
| Automatic tool change system | Tool magazine capacity | set | 30 |
| Maximum tool outer diameter (when fully loaded) | mm | 112 |
| Expanding the diameter of the hollow blade | mm | 200 |
| Maximum tool length | mm | 350 |
| Maximum tool weight | kg | 18 |
| Tool change time (knife to knife) | sec | 6 |
| Precision VD13441 (JISB6338) | Positioning accuracy | mm | P0.012(±0.004/300) |
| Repetitive accuracy | mm | Ps0.001(±0.003) |
| Other | Electricity dernad | Kva | 30 |
| Barometric pressure demand (minimum) | kg/cm² | 6 |
| Cuting fluid capacity | liter | 350 |
| Machine footprint | mm(approximately) | 5600*3600 |
| Machine height | mm(approximately) | 3150 |
| Machine weight | kg(approximately) | 10000 |
