| US$10,000.00-15,000.00 | 1 Piece (MOQ) |
| Grinding diameter (mm) | φ5-φ100 | |
| Grinding maximum depth (mm) | 350 | |
| Maximun rotation angle of headstock (°) | 20 | |
| rotating speed of work piece (r/min) | 180-500 4 levels steps 180-500 4levels steps | |
| rotating speed of grinding wheel (r/min) | 10000,20000 | |
| swing diameter of workpiece inside the shell | 260 | |
| outside the shell | 480 | |
| Total power of machine tools (KW) | 5.5 | |
| For standard test sample | Roundness(mm) | 2.5 |
| Cylindricity (mm) | 4 | |
| Machine dimensions (mm) | 3163*260*300 | |
| Machine weight (kg) | About2500 | |
