Fengyuan Heavy Type Block Stone Cutting Machine

Product Description

Product Description
The Multi-blade Stone Block Cutting Machine FY-1650, equipped with multiple blades, is suitable for cutting granite, basalt, marble, and quartz blocks into slabs. It demonstrates excellent performance in cold regions such as Russia. This classic and practical bridge saw is capable of cutting blocks into both thin and thick slabs. It features a Siemens PLC control system and Hiwin linear guide with oil bath. Additionally, it can accommodate up to 30 thin saw blades for efficient operation.
Product Parameters

Model No.			FY-1650	FY-2250	FY-2850	FY-3450	Remarks
Main Frame Specification	Crossbeam Type	/	DL-QS900	DL-QS900	DL-QS900	DL-QS900	** The parameters in this part can be customized before the machine is produced; once finished, they become fixed.
	Crossbeam Height	mm	900	900	900	900
	Crossbeam Length	mm	7000	8500	9500	10500
	Crossbeam Width	mm	800	800	800	800
	Sidebeam Length	mm	5000	6500	8000	9500
	Spindle Diameter	mm	120/150	120/150	120/150	120/150
	Middle Frame Height	mm	2550	2550	2550	2550
Machine Working Stroke	X-axis	mm	4500	5400	5800	6200
	Y-axis	mm	2800	4300	5800	7300
	Z-axis	mm	900	900	900	900
Motor Power	Spindle Rotation	kw	90/110	90/110	90/110	90/110	** The parameters in this part can be customized before the machine is produced; once finished, they become fixed.
	Lifting Cylinder	kw	4	4	4	4
	Left and Right Travel	kw	5.5	5.5	5.5	5.5
	Front and Back Travel	kw	2.6*2	2.6*2	2.6*2	2.6*2
	Gross Power	kw	90	90/105	90/105	90/105
	Gross weight	T	22.5	25.5	27.5	30
	Dimensiona(L x W x H)	mm	8500*5500*3850	10000*7000*3850	11000*8500*3850	12000*10000*3850

Detailed Photos
Main Features 1) The Siemens smart PLC control system ensures high levels of automation performance and ease of use.
2) The machine's structure is made steady and the lifting stable through the adoption of four pillars for spindle sliding.
3) A two-slider frame structure, driven synchronized by a screw, provides high stiffness and stability.
4) The sliding system of the X and Y axes on linear guides and racks, both lubricated in an oil bath, guarantees smooth operation and high production. Machine Parts
Siemens smart PLC control system
Machine Parts
Name: 6 big strong pilllars
Use: sliding guide for spindle
Covered by fabric for preventing pollution.

Linear Guide
Brand: Hiwin
Original: Taiwan, China
Famous products, top quality use on crossbeam and carling for good performance.
Machine Parts
Name: Circle Blade Original: China Up to 32 pieces of blade can be hanged for efficient production of thin slabs.

Factory View
Workshop

---
