DR9074-2.4G(PN01.1)
QCN9074 802.11ax 4x4 MU-MIMO 2.4GHz wifi6
QCN9074 11ax 4x4 2.4G M.2
Features
■ Qualcomm Atheros QCN9074
■ 2.4GHz, max 23dBm per chain, up to 1147Mbps
■ Single Band 2.4GHz 4x4 WiFi 6 (802.11ax)
■ 4 spatial streams (4SS)
■ M.2 E Key Interface
■ PCI Express 3.0 Interface

Absolute Maximum Rating

Parameter
Rating
Unit
Operating Temperature Range
-20 to 70
ºC
Storage Temperature Range
-40 to 90
ºC
Operating Humidity Range
5 to +95 (non-condensing)
%
Storage Humidity Range
0 to +90 (non-condensing)
%


Hardware Specifications

Symbol
Parameter
Chipset
Qualcomm Atheros QCN9074
WLAN Host Interface
PCI Express 3.0 Interface
System Memory
2Mbit serial I²C bus EEPROM
Standard Operating Voltage
5V
Operating Systems
QSDK
Host Interface
M.2 E Key
Antenna Cable / Port
4 x MMCX Connectors,4T4R
Frequency Range
2.412GHz-2.472GHz
Data Rates for WALN
2.4GHz, max 23dBm per chain, up to 4949Mbps
Channel Spectrum Widths for WLAN
Support 20/40MHz at 2.4GHz
Modulation Techniques
OFDMA: BPSK, QPSK, DBPSK, DQPSK,16-QAM, 64-QAM, 256-QAM,1024-QAM
Temperature Range
Operating: -20°C to 70°C, Storage: -40°C to 90°C
Humidity
Operating: 5% to 95% (non-condensing), Storage: Max. 90% (non-condensing)
Certification
TBD
Power Consumption
TBD
Reference Design
PN01.1
Dimensions (WxHxD)
57mm x 63mm x 6mm


 M.2 Pin Definitions

Pin No.NamePin No.Name
1GND
2VDD3P3_PCIE
3
4VDD3P3_PCIE
5
6PCIE_LED0
7GND
8GPIO46_WCI2_UART_TXD_PCIE
9TP19
10GPIO47_WCI2_UART_RXD_PCIE
11
12
13
14
15VDD_XPA_PCIE
16PCIE_LED1
17VDD_XPA_PCIE
18GND
19VDD_XPA_PCIE
20
21VDD_XPA_PCIE
22
23VDD_XPA_PCIE






33GND
32
35PCIE0_RX0_P
34
37PCIE0_RX0_N
36
39GND
38MOD_BT_STS_2
41PCIE0_TX0_P
40MOD_WL_ACT_2
43PCIE0_TX0_N
42PINE_BT_ACT_2
45GND
44MOD_BT_STS
47PCIE0_REFCLK_P
46MOD_WL_ACT
49PCIE0_REFCLK_N
48PINE_BT_ACT
51GND
50
53PCIE0_CLKREQ_3P3_N
52PCIE0_PERST_3P3
55PCIE0_WAKE_3P3_N
54
57GND
56
59PCIE0_RX1_P
58
61PCIE0_RX1_N
60
63GND
62
65PCIE0_TX1_P
64
67PCIE0_TX1_N
66
69GND
68
71
70
73
72VDD3P3_PCIE
75GND
74VDD3P3_PCIE
