Tapered Roller Bearing/Skfnsk/Separable Bearing/30203/Roller Bearing/Single-Row Tapered Roller Bearing/Bearing

Product Description

Tapered Roller Bearing/Skfnsk/Separable Bearing/30203/Roller Bearing/Single-Row Tapered Roller Bearing/Bearing
Single row tapered roller bearings are designed to withstand combined radial and axial loads, with low friction during operation. The inner ring component with rollers and cages can be installed separately from the outer ring. This separable and interchangeable bearing is easy to install, disassemble, and maintain. Installing a single row tapered roller bearing against another bearing can obtain preload and achieve the application of rigid bearings.
The advantages of single row tapered roller bearings are:
-High axial and radial bearing capacity
-Can withstand unidirectional axial load
-Low friction
-Long service life
-Detachable and interchangeable components

Model	Basic Dimensions			Basic Dynamic load rating		Rated Speed
	Inner Diameter	Outer Diameter	Width	Trends	static state	Reference speed	Limiting Speeds
	d[mm]	D[mm]	T[mm]	C[kN]	C0[kN]	[r/min]	[r/min]
30202	15	35	11.75	18.5	14.6	17 000	20 000
30203	17	40	13.25	23.4	18.6	15 000	18 000
30204	20	47	15.25	34.1	28	12 000	15 000
30205	25	52	16.25	38.1	33.5	11 000	13 000
30206	30	62	17.25	50	44	9 000	11 000
30207	35	72	18.25	63.2	56	8 000	9 500
30208	40	80	19.75	75.8	68	7 000	8 500
30208 R	40	80	19.75	75.8	68	7 000	8 500
30209	45	85	20.75	81.6	76.5	6 300	8 000
33020	100	150	39	278	390	3 400	4 000

Basic knowledge of bearings
Why choose rolling bearings?
Rolling bearings support and guide the rotation or oscillation of machine components - such as axles, axles, or wheels - with minimal friction and transmit loads between machine components. Rolling bearings have high precision and low friction performance, thus achieving high rotational speeds while reducing noise, heat, energy consumption, and wear. This type of bearing is cost-effective and is a typical interchangeable machine component that meets national or international dimensional standards.
Ball and roller bearings
Distinguish the two basic types of rolling bearings using the two basic types of rolling elements:
* Ball → Ball bearing
* Roller → Roller bearing
The difference between a ball and a roller is the way it contacts the raceway.
The ball makes point contact with the bearing ring raceway. As the load acting on the bearing increases, the contact point becomes an elliptical area. If the contact area is small, the rolling friction is also small, which allows the ball bearing to adapt to high-speed operation, but limits its load-bearing capacity.
The roller and bearing ring raceway make line contact. As the load on the bearing increases, the contact line becomes a rectangle. Due to the larger contact area and the resulting friction, roller bearings can withstand heavier loads but lower speeds compared to ball bearings of the same size.
Radial and thrust bearings
Rolling bearings are divided into two categories based on the main load direction they bear:
* Radial bearing
Radial bearings can withstand loads perpendicular to the shaft. Some radial bearings can only withstand pure radial loads, while most radial bearings can also withstand axial loads in one direction, and in some cases, they can also withstand axial loads in both directions.
* Thrust bearing
The thrust bearing mainly bears loads along the axial direction. According to the design, thrust bearings can support unidirectional or bidirectional pure axial loads, but some can additionally withstand radial loads. Thrust bearings cannot achieve speeds as high as radial bearings of the same size.
The contact angle determines which category the bearing belongs to. Bearings with a contact angle ≤ 45 ° are radial bearings, while others are thrust bearings.
