New Multifunctional Filtering Washing and Drying Equipment Agitated Nutsche Filter Dryer

Product Description

1. Equipment Application
NFD series filtration, washing and drying machines (also known as tank-type three-in-one) are widely used in solid-liquid separation, solid washing, solid drying and solid unloading in the pharmaceutical, chemical, pesticide, food and other industries. The whole process can be closed The continuous operation is the selection equipment for filter washing and drying in the above industries.
2. Equipment Structure
The equipment is a stainless steel vertical container, consisting of tank device, stirring device, shaft end sealing device, lifting mechanism, hydraulic device, tank base (fixed or detachable), heating device, transmission mechanism, filter device, unloading device , sampling device, washing (cleaning) sterilization device, travel knowledge device, touch screen and manual operation control device, hydraulic pump station, main electric control cabinet (including inverter, PLC, etc.), and other electrical accessories and other components. Realize the integration of machine, electricity and instrument.
3. Equipment Process Characteristics
The whole process of filtration, washing and drying is completed continuously in the same container.
a. Filtration: operate under vacuum to achieve solid-liquid separation. During filtration, the filter cake is flat, and the solid-liquid separation effect is good.
b. Washing: There is a 360° rotating spray device on the inside of the container, so that the cleaning (washing) liquid is evenly distributed in the container, which can realize the cleaning inside the container and the paddle washing of materials, and the filter cake and the washing liquid are mixed by stirring the lifting paddle. , so that the slurry crystal and filter cake can be fully washed.
c. Drying: The filter cake is loosened layer by layer by the stirring blade, the heating device of the equipment evenly heats the filter cake, and the wet material is heated with hot gas in a vacuum state to accelerate the evaporation and achieve the purpose of drying.
d. Unloading: Scrape and loosen the material, and push it through the stirring blade to automatically unload the material from the discharge port on the side of the tank wall.
4. Parameter Table

Model	Inner Diameter mm	Filter Area m2	Volume m3	Filter Thickness mm	Motor kw	Chamber Height mm	LiftingHeight mm	Height mm
NFD400	400	0.12	0.06	150	0.75	500	150	1300
NFD600	600	0.28	0.22	200	2.2	800	200	2200
NFD800	800	0.5	0.46	250	4.0	900	250	2350
NFD1000	1000	0.78	0.86	250	4.0	1100	250	3250
NFD1200	1200	1.1	1.2	300	7.5	1100	300	3400
NFD1400	1400	1.54	1.8	400	7.5	1150	400	3850
NFD1600	1600	2.0	2.4	400	11.0	1200	400	3980
NFD1800	1800	2.5	3.0	400	11.0	1200	400	4100
NFD2000	2000	3.1	4.0	450	15.0	1250	450	4300
NFD2200	2200	3.8	4.8	450	18.5	1250	450	4400
NFD2400	2400	4.5	5.6	450	18.5	1250	450	4450
NFD2600	2600	5.3	6.9	450	22	1300	450	4580
NFD2800	2800	6	8	500	22	1300	500	4660
NFD3000	3000	7	10	500	30	1400	500	4760
NFD3200	3200	8	11	500	30	1400	500	5000
NFD3500	3500	9	12	500	30	1400	500	5200
NFD3600	3600	10	14	500	37	1400	500	5350

Company Show
Company introduction: Jiangsu Xingxing Drying Equipment Co., Ltd.
Jiangsu Xingxing Drying Equipment Co.,Ltd has established in 1998 and it covers an area of 15000 square meters, possesses fixed asset of USD 7 million. The products have exported to US, Singapore, India, Ukraine, Russia, Korea and so on. The company have advanced production equipment , excellent technical team and after-sales service.
CERTIFICATE
Package:wooden case
Service:
pre-sale service
We Invite customers to visit our company and communicate on technical requirements face to face.
sale service
Responsible for debugging the equipment according to customers' requirements of various technical data. Our engineers will train our customers about equipment features and operation key points to make sure the equipment running in the best condition.
after-sale service
We provide installation, debugging, maintenance, training and other services; Provide relevant technical data, equipment, software and related GMP certification materials;Set up after-sales service hotline, and arrange personnel to visit customers every year to know more customer needs,like customer operation problems in the process of production equipment.
quality promise
Our company promises strictly operate the ISO9001 quality system certification standards and pharmaceutical equipment GMP audit requirements,promise we provide new equipment. Advanced technology,good quality.Equipment operation safe reliable, affordable, easy to maintain.
Equipment warranty period is one year,all the parts for the equipment choose well-known brand.During the warranty when equipment have problem in quality like equipment failure and damage,the company for free maintenance or replacement.
We look forward to cooperating with partners from all over the world to build win-win cooperation relationship in long term. Welcome for your visiting.
Previous Exhibition
FAQ:
1. Q: Please describe your warranty period.
A: 15 months after the equipment is arrived at the destination port or 12 months after the installation and commissioning of the equipment, whichever comes first.
2. Q: Do you provide on-site installation and commissioning?
A: Yes, we do. If on request, we'll provide the guidance of on-site installation and commissioning. Usually one mechanical engineer and one electrical engineer to assist.
3. Q: How about the cost of on-site installation and commissioning guidance?
A: The cost consists of round-trip air tickets, room and board expenses, service cost (labor cost), and site transportation (or directly provided by client), which shall be paid additionally.
4. Q: Are you a factory or a trading company?
A: We are a professional manufacturer. We have own factory and pilot plant for customers to do sample testing.

---
