Higher Precision Mini Grinder Hydraulic Surface Grinding Machine

Product Description

Product Description




Standard equipment: Coolant tank Elector magnetic chuck Wheel dresser base Flange and wheel extractor Standard wheel Balance arbor
Working lamp Leveling wedge and foundation bolt Normal elector magnetic chuck controller PLC auto grinding controller (only for
AHD model)

Optional equipment: Balancing stand Manual paraller wheel dresser Coolant tank with magnetic separator Coolant tank with paper filter Coolant tank with paper filter and magnetic separator Dust collector Luxurious elector magnetic chuck controller Notice:
1.H mean: hydraulic transmission on longitudinal, manuatransverse and vertical
2. AH mean: auto feed on transverse, hydraulic
transmison longitudinal, manual on overtical. 3. AHR mean: auto feed on transverse, hydraulic transmison longitudinal, rapid
movement on vertical. 4. AHD mean: auto feed on transverse, hydraulic transmison longitudinal, auto feed on vertical.
Specification

Model			Unit	13805-1
						SG-3063AH
						SG-3063AHR
						SG-3063AHD
Table sze (W*D)			mm	305*635
Table travelX*Y)			mm	765*340
Max. dstance from spindle center to table			mm	580
Magnetic chuck size			mm	300*600
Speed of table longtudinal movenment			m/min	7-23
Transverse movement	Auto feed	mm/min	0.1-8
		Rapid speed	mm/min	990
		Feed of handwheel	mm/div	0.02
Wheelhead vertical movement	Auto feed	mm/min	(AH/AHR model)/0.05/0.01/0 02/0.03/0.04/0.05(only AHD model)
		Rapid speed	mm/min	(AH model)/460(AHE/AHD model)
		Feed of handwheel	mm/div	0.05
Grindng wheel	Speed	rpm	3450(60Hz)
		size(OD*W*ID)	mm	1750(60Hz)
Spindle motor			kw	5.5
Hydranlic motor			kw	2.2
Cooing pump molor				0.125
Elevating motor			kw	AH/AHR model)/0.25 (AHR model)/0.05(AHD model,seno motor)
Cross leed molor			kw	0.04
Max. loading capacity of table			kg	270
Total raled power			kw	9
Height of machine			mm	1890

Company Profile
SJR Machinery Co., Ltd. , was founded in 1984, which is the main partner member of China Jiangsu International Economic-Technical Cooperation Corporation. Our company specializes in the manufacture and import/export of brand new industrial machinery and tools. We are capable of producing more than 80 types of machines.Sincerely welcoming you to contact us for more information, we look forward to becoming your supplier in the near future.
Order Evaluation
Exhibition
Customer Photos
Certifications
FAQ
1. How can I choose the most suitable machines ? A: Please tell me your specifications ,we can choose the best model for you , or you can choose the exact model .
You can also send us the products drawing ,we will choose the most suitable machines for you .

2. What is your payment terms ?
A: 30% down-payment after contract ,and 70% payment before shipment, Meanwhite it can be discussed according to your situation.

3: Where is our factory located? How can I visit there?
A : Our factory is located in No. 52 Linyin Road, Economic and Technological Development Zone, Nantong City, Jiangsu Province ,226001 China. You are warmly welcomed to visit us.

4. What is your delivery time ?
The delivery depends on different machines with different configurations. Please contact us to confirm it is in stock or not.

5. Can you send the service engineer to our company ?
We have engineers stationed in Canada, Egypt, and Algeria. The after-sales service system is very perfect.
