Three Heads Heavy Duty Wide Belt Calibrate Polishing Sander Machine

Product Details

Product Details

Product Description

Product Description
Heavy Duty Three Heads Wide belt Calibrate Polishing Sander Machine
1. Main features:
This machine is suitable for the thickness setting, light sanding and fine polishing of the small
type wood board, veneer, chipboard, fiberboard, middle dense board, aminatedboard, and variety
of sheet materiaks for the funiture factory and the board mill.
The roller's diameter is much bigger and the rollers have been run-balanced precisely, which makes running smoothly and improves the sanding power.
2. Technical parameters:
Model. NoBSG1313R-R-P
1.Sanding width40-1300mm
2.Sanding thickness2.5-80mm
3.Size of sanding belt1330*2800mm
4.Voltage380V 50Hz
5.The first headMotor 75kwφ294mm steel roller
6.The second headMotor 55kwφ400mm robber roller
7.The third head Motor 22kw hard polish pad
7.Transport reducer7.5kw
8.Transoprt speed20-40m/min
9.Lifting motor0.75kw
10.brushing motor0.75kw
11.Total motor154kw
12.Operating pressure0.6MPa
13.Dust extraction15000m³/h
14.Speed of dust extraction25-30m/s
15.Dimension 3150*2900*2440mm
16.Weight10500kg

3. More Pictures
