TN-VA LCD Panel with Pin Connetor Sick Screen Print (8D0013)

Product Description

Product Description Graphical LCD 128*64 Specifications:
Module Size: 78(W)*37.40(H)*5.30(T) mm
View Area: 53.4(W)*25.2(H) mm Display mode: Positive, Transmissive
Driving IC: ST7567
IC bonding: COG
DOT matrix: 128x64
Connector: FPC
Display type: STN
View direction: 6 o'clock Mechanical Data

NO	ITEM	SPECIFICATION	UNIT
1	Dot Marrix	128(W) x 64(H)	dot
2	Module Size	78.00(W)*37.40(H)*5.30(T)	mm
3	View Area	53.4(W)*25.2(H)	mm
4	Active Area	46.05(W)*22.05(H)	mm
5	Dot Size	0.33(W) x 0.315(H)	mm
6	Module Thickness	5.30	mm

Spec:
SIZE:length*width*highth
DISPLAY TYPE: VA TN DISPLAY
LCD OPERATIONG VOLTAGE :5.0v?(3V-5V.>2.8V IS OK)
OPERATING TEMP:-20-70C
STORGER TEMP:-30-80C
DRIVE MODE: 1/4DUTY ,1/3BIAS
VIEWING DIRECTION: 6H(BOTTOM VIEWING)---(12H,6H,3H,9H)
POLARIZER TYPE: FRONT :TRANSMISSIVE,
BACK: TRANSMISSIVE
CONNECTOR: PIN (20)
BACKLIHGT: WHITE WITH TWO LIGHT,/BLUE BL (CUSTOMER DESIGN)
------------------------------------------------------------------------------------------------------------------------------------ Conditions and terms : Package:Cusomized packages, poly bag/customized blister/color box etc.As per your need. Delivery company:DHL/UPS/TNT or as customer requireed Payment:T/T, payment, west union Our Services : 1.Logo printing, customized package and accessories are available. 2.OEM/ODM orders are warmly welcome. 3.Unconditional replacement if Product quality problems. 4.TEL:008613827213376 judy FAQ : 1.Q:Are you a factory or trading company? A:We are manufacturer. 2.Q:Where is your factory located?How can I wisit there? A:Our factory is located in Shenzhen City, China.You can fly to Hongkong airport directly, Welcome to visit our factory. 3.Q:How can I get some samples? A:We don't provide free one, but we will minux the extra price when you reorder with the suitable quantity. And you will win the 3% discount.:) 4.Q:How to proceed the order if I have logo to print? A:First, Artwork for visual confirmation, and next is Sample picture or sending sample to you for confirmation, finally we will go to mass production. 5.Q:How does your factory do regarding quality control? A:Quality is the priority.We always attach great importance to quality controlling fromthe start to the end.Our factory has gained CE, FCC, RoHS certification.

---
