| US$5,000.00-10,000.00 | 1 Piece (MOQ) |
| MODEL | Z3050X13 |
| Max. drilling diameter | ø50mm |
| Colunu diameter | 300mm |
| Distance between spindle axis and column | 335-1300mm |
| Distance of headstock horizontal movement | 960mm |
| Distance between spindle nose and woring surface of base | 280-1170mm |
| Rocker arm lifting distance | 630mm |
| Spindle travel | 260mm |
| Spindle taper | MT 5 |
| Range of spindle speeds(6 steps) | 38,100,182,225,450,910r/min |
| Range of spindle feeds (3 steps) | 0.10,0.16,0.25mm/r |
| Max. permissible feed pressure of spindle | 6300N |
| Rocker arm lifting speed | 1.3m/min |
| Rocker swing angle | ±180° |
| Spindle motor power | 3 kW |
| Elevating motor power | 0.75kW |
| Cooling pump motor power | 0.04kW |
| Machine weight | 2300kg |
| Overall dimension | 2080x820x2320mm |
