| US$1,000.00-3,000.00 | 1 Piece (MOQ) |
| Item | Unit | Z3025×10/1 | Z3032×8/1 | Z3032×10/1 | |
| Max.drilling dia. | mm | 25 | 32 | 32 | |
| Distance between spindle and column | Max. | mm | 1000 | 820 | 1000 |
| Min. | mm | 300 | 320 | 300 | |
| Distance between Spindle and base | Max. | mm | 1030 | 850 | 1000 |
| Min. | mm | 250 | 90 | 250 | |
| Spindle taper(MORSE) | NO.3 | NO.4 | NO.4 | ||
| Spindle travel | mm | 120 | 120 | 120 | |
| Spindle speeds number | Steps | 16 | 6 | 16 | |
| Spindle speeds range | r.p.m | 32-2500 | 75-1220 | 32-2500 | |
| Number of spindle feeds | Steps | 8 | 3 | 8 | |
| Range of spindle feeds | mm/r | 0.10-1.25 | |||
| Table size | mm | 450×670 | 450×670 | 450×670 | |
| Main motor power | kW | 1.5 | 1.5 | 2.2 | |
| Net/Gross weight | kg | 1600/1900 | 1200/1700 | 1600/1900 | |
