Combination Lathe Machine Jyp260 Jyp260L

US$1,200.00-2,000.00 1 Piece (MOQ)

Basic Info.

Model NO.

JYP260 JYP260L

Type

Horizontal Lathe

Processing Accessory

Metal

Guide Rail

Horizontal Guide Rail

Tool Holder

4 Way Tool Post

Power Source

Electric

Controlling Mode

Artificial

Automatic Grade

Manual

Setting Mode

Floor-type

Precision

High Precision

Certification

CE, RoHS, ISO 9001

Condition

New

Max.Swing Over Bed

250mm

Spindle Taper

Mt4

Spindle Bore

26mm

Transport Package

Plywood Case

Specification

3200kgs

Trademark

HOYONG-TRD

Origin

Shandong, China

HS Code

84581900

Production Capacity

10 PCS/Month

Product Description

COMBINATION LATHE JYP260/JYP260L
Most popular ,widely useful combination machine
V-way bed is precision ground
Gear head enables to change speed quickly
MT4 spindle hole gets more capacity
Spindle is supported by precision bearing
T-slotted cross slide
Power longitudinal feed allows threading
Adjustable gids for slideways
Top design of gearbox gets more function
Mill head can be tilted ± 90° .
Tolerance test certificate, test flow chart included.
SPECIFICATIONS:

MODEL	JYP260
Distance between centers	450/ 700mm
Swing over bed	250mm
Taper of spindle bore	MT4
Spindle bore	26mm
Step of spindle speeds	6
Range of spindle speeds	115-1620rpm
Range of inch threads	8-56T.P.I
Range of metric threads	0.4 -3.5mm
Travel of cross slidel	140mm
Taper of tailstock quill	MT3
Motor	750W
Taper of spindle bore	MT2
Spindle stroke	50mm
Spindle speed	50-2250rpm
Max.distance spindle to table	280mm
Max.distance spindle to columm	170mm
Head tilt	±9 0 °
Motor	500W
Packing size	1270/1510 × 670 × 1100mm
Net weight	180kg / 200kg

STANDARD ACCESSORIES :	OPTIONAL ACCESSORIES :
3-jaw chuck Dead centers Reductions sleeve Change gears Oil gun Some tools	Steady rest Follow rest Face plate 4 jaw chuck Live center Stand Lathe tools Thread chasing dial Lead screw cover Tool post cover Disc milling cutter Mill chuck Side brake
