Sustainable Plastic Bucket Injection Molding Equipment for Sale

Product Description

INTERNATIONAL SPECIFICATION	NO	HTF-368/JD
INJECTION UNIT		A	B	C
Screw Diameter	MM	60	65	70
Screw L/D Ratio	L/D	23	22	20
Shot Size(Theoretical)	CM3	1000	1174	1362
Injection Weight(PS)	G	910	1068	1240
Injection Rate	G/S	258	302	350
Injection Pressure	MPA	214	182	157
Screw Speed	RPM	0-154
CLAMPING UNIT
Clamping Force	KN	3680
Toggle Stroke	MM	630
Space Between Tie Bars(W*H)	MM	680*680
Max.Mold Height	MM	710
Min.Mold Height	MM	250
Ejector Stroke	MM	160
Ejector Force	KN	89
Ejector Rods Number	PC	13
OTHERS
Max.Pump Pressure	MPA	16
Pump Motor Power	KW	37
Heater Power	KW	18.5
Machine Dimension(L*W*H)	M	6.8*1.8*2.35
Machine Weight	T	11.9

FAQ
1. who are we? We are based in Zhejiang, China, start from 2017,sell to South America(20.00%),Mid East(20.00%),Southeast Asia(15.00%),Africa(13.00%),Eastern Asia(10.00%),Eastern Europe(10.00%),South Asia(5.00%),Domestic Market(2.00%),Oceania(1.00%),Western Europe(1.00%),Southern Europe(1.00%),Central America(1.00%),Northern Europe(1.00%). There are total about 11-50 people in our office. 2. how can we guarantee quality? Always a pre-production sample before mass production; Always final Inspection before shipment; 3.what can you buy from us? Injection Molding Machine; Plastic Machinery; Plastic Mould; Blow Molding Machine; Plastic Auxiliary Equipment 4. why should you buy from us not from other suppliers? Servo energy saving, highest precision, clamping force 500KN-30000KN, European safety standards, more than 30 years experience in injection molding machines, better quality than other companies, 100% real factory, cheapest price, 24 hours best service. 5. what services can we provide? Accepted Delivery Terms: FOB,CFR,CIF,EXW,DDP,DDU,Express Delivery,DAF,DES; Accepted Payment Currency:USD,EUR,HKD,CNY; Accepted Payment Type: T/T,L/C,PayPal,Western Union,Cash; Language Spoken:English,Chinese,Spanish,Portuguese,Arabic,Russian,Hindi

---
