High-Speed Solid-Liquid Separation for The Food Industry Fish Meal, Protein, Juice, Wine, Milk, Almond, Oats, Tomato Decanter Centrifuge

Product Description

High-Speed Solid-Liquid Separation for the Food Industry | Fish Meal, Protein, Juice, Wine, Milk, Almond, Oats, Tomato | Decanter Centrifuge

Product Description
Description:
3 phase liquid-liquid-solid Decanter centrifuges, also called tricanter , Taking advantage of the principle that the heavy liquid,light liquid and solid phase, with different density and mutually insoluble in the mixed liquid, gain different sedimentation speed in the centrifugal force field or gravity force field, separating stratification or causing the solid particles in the liquid to deposit can be achieved.It is the popular machine throughout the world and widely used in the crude oil separation.Specially used for remove sludge and water from crude oil.


Separation principle: The decanter is driven by two motors. The main motor drives the bowl and the housing of differential mechanism to rotate through belt, while the auxiliary motor drives through the belt pulley the input shaft of the differential mechanism to rotate, which, after speed change, drives the helical to rotate. In this way the bowl and helical rotate in the same direction but with certain differential speed. When the material to be processed (blended liquid consisting of solid phase and liquid phase) enters the inner cavity of the helical propeller through feeding pipe, after being accelerated by the two-way conical accelerator, it flows out of the material outlet, and flows into the bowl wall through inner cloth cylinder. The light, heavy and residue phases that make up the suspending liquid, under the action of different centrifugal force, the residue phase quickly subsides onto the inner wall of the bowl, and the heavy phase adheres close to the surface of the residue phase rather slowly, while the light phase adheres close to the surface of the heavy phase rather slowly, forming a dividing plane between the two phases. As the sedimentation of heavy phase increases, the top end of helical blade enters into the sedimentation layer of heavy phase. At this time the bowl and helical propeller are rotating in the same direction at high speed and with a certain difference in speed. This relative difference in rotation speed enables the helical to propel heavy phase particles to move toward the material outlet at the small end, whereas the light phase, through the helical passage, flows toward the liquid phase outlet at the large end, and flows out through the overflow plate with different R values.

Type	Max speed	Max separation value	Capacity	Power	Weight	Dimension(mm)
LWS230*1000	5600 r/min	4000 g	0.5-3 m3/h	7.5-15 kw	900 kg	2300*700*1200
LWS380*1520	4000 r/min	3450 g	1-5 m3/h	18.5-22 kw	3200 kg	3500*1000*1500
LWS380*1720	3800 r/min	3070 g	3-6 m3/h	22-30 kw	2800 kg	3400*1100*1400
LWS430*1720	3700 r/min	3290 g	8-10 m3/h	30-37 kw	3200 kg	3500*1200*1500
LWS430*1950	3500 r/min	2950 g	8-12 m3/h	37-45 kw	3500 kg	3800*1200*1500
LWS500*2000	3500 r/min	3420 g	10-20 m3/h	45-55 kw	6000 kg	4300*1850*1300
LWS600*2460	3000 r/min	3020 g	12-25 m3/h	55-75 kw	6500 kg	4800*1500*1700
LWS650*2600	2900 r/min	3050 g	15-30 m3/h	75-110 kw	7500 kg	5200*1600*1800

Main feature: 1. Two motor, two frequency inverter drive system, realize differential speed stepless regulation and energy return
2. Spiral stoker blades: Surfacing welding tungsten carbide grinding
3. Drum cone cylinder material outlet: Replaceable wear resistant, corrosion resistant ceramic alloy bushing.
4. Main bearing: Sweden NSK
5. Main sealing parts: Taiwan SOG, material is Nitrile butadiene rubber
6. Electrical protection: overload, phase loss, torque protection
7. Main and vice inverter use common DC bus, vice motor's function is generating electricity ( save electricity)
8. PLC remote control(Customer selection)
Product More Pictures


Product Packaging
Our Honor
Our Service
1. We will provide one-year warrantee to make sure your machine runs consistently.We always keep certain inventory level of spare parts,which means the replacements can be shipped to you right away.
2. Consultant services for whole machine life,24 hours technical support by email and telephone.
3. Send technicians to the jobsite for guiding the installation and adjustment,training operators and finishing the check and accept together with you.
Company Profile

LIAOYANG WANDA MACHINERY CO.,LTD is specialized in design, development, manufacture and sale of chemical and foodmachinery. Our products includes decanter centrifuge, tubular centrifuge, disc centrifuge, plate series centrifuge, filter press machine and so on.
Looking to the future with a commitment to design innovation and quality products, supported by an outstanding level of customer service. The unexcelled quality machinery can be easily obtained from us because we maintain the quality and standard of our products from incoming raw materials to the finished products. Our company follows strict quality controls and various systematic procedures. We take utmost care of quality at every stage of the manufacturing process.
Our research and development wing is our asset that develops and incorporates innovative ideas and products. Our Team is full of experienced and qualified professionals, who have sound knowledge about the quality of our machinery. Our products are far sold to Europe, U.S.A., and the southeast Asia. They are well received by customers both at home and abroad.
FAQ
1. What data is required to confirm the model?
(1) Materials to be separated (2) Treatment capacity per hour (3) Solid content
2. What certificates do you have?
We can provide CE, ISO9001, etc
3. What is the warranty period of the equipment?
Normally 1 year warranty
4. Can we visit your factory?
Of course, we sincerely invite you to visit
5. Can we bring our own materials to your factory for experiments?
Of course, you are welcome at any time. We will arrange professional engineers and technicians to do experiments and analyze data
for you on site
6. Can it be customized?
Of course, our equipment can be customized according to the actual requirements of customers.
7. How long is the construction period?
It's about 30 days, but it also needs to be determined according to the specific equipment model, order number, etc., But if you need it urgently, please let us know, we can arrange the factory to rush production.
8. Will you provide installation services?
If you need, we can arrange professional technicians and engineers to install and debug on site.

---
