Chemical Blender Blending Mixing Mixer Machine Equipment

US$5,000.00-30,000.00 1 set (MOQ)

Basic Info.

Model NO.
EYH
Application Area
Chemical
Certification
CE, ISO
Condition
New
Main Material
Stainless Steel
Mixing Drum Shape
Drum
Stirring Type
Diving
Working
Diffusion Mixer
Professional Manufacturering
Strong Technical Power
Good Price
Experienced After Sale Service
Payment
Tt L/C
Delivery
90days
Certificate
ISO9001 ISO14001
Mixer Type
Powder Mixer
Layout Type
Horizontal
Operating Type
Cycle Operating
Transport Package
Standard Wooden Case
Specification
EYH
Trademark
Yuzhou
Origin
China
HS Code
847982
Production Capacity
5-4000kg Per Batch

Product Description

PRODUCT CATEGORIES
Product Description EYH Series Two Dimensions Mixer
With Large production capacity, EYH two-dimensional motion blender is a high efficiency and energy saving blender . It is mainly made up of drum, swing rack and frame. Supported by four wheels, the drum is installed in the swinging rack. Materials to be mixed will be rotated when the cylinder is rotating, and will be mixed from left to right and vice versa when the cylinder is swinging. As a result of these two motions, this two-dimensional motion blender is suitable for blending of all powder and granule materials.
Model Barrel volume Loading capacity Maximum loading capacity Number of rotation Total motor power Overall dimension Gross weight Barrel weight
EYH-10 10 5 2.5 85 0.021 310×400×450×395 15 4
EYH-30 30 15 7.5 61 0.19 540×580×900×700 60 8.5
EYH-60 60 30 15 50 0.4 700×730×1100×990 115 15
EYH-150 150 75 37.5 37 1.15 800×1050×1450×1340 190 50
EYH-300 300 150 75 30 1.15 900×1350×1550×1400 340 60
EYH-600 600 300 150 23.6 3 1170×1640×2050×1910 1150 140
EYH-800 800 400 200 19.8 3 1320×1950×2150×2000 1600 200
EYH-1000 1000 500 250 19.8 3 1360×2040×2300×2170 1700 240
EYH-1500 1500 750 375 16.2 4.4 1580×2400×2550×2330 2000 320
EYH-2000 2000 1000 500 16.2 7.4 1740×2600×2770×2550 2600 430
EYH-3000 3000 1500 750 13.8 11 1800×2900×2950×2800 3500 620
EYH-4000 4000 2000 1000 12.8 13 1970×3300×3300×2950 4100 700
EYH-6000 6000 3000 1500 11.2 18.5 2300×2900×3800×3100 6100 1100
EYH-8000 8000 4000 2000 10.4 22 2540×4100×4050×3650 7900 1450
EYH-10000 10000 5000 2500 9 30 2900×4500×4400×4020 9500 1650
PRODUCT INTRODUCTION Working Principle of EYH Series Two Dimensions Mixer
The mixing barrel swings while rotates so that the materials in the barrel can be fully mixed. Because the discharge port of the barrel is out of the barrel cenbtreline, the mixer features quick mixing and discharging, as well as high volume mixing capacity.
Features
1. This two-dimensiona blending machine is sterile, dust-free and totally enclosed.
2. Two-dimensional motion blender features quick blending and discharging, as well as high volume mixing capacity.
Parameters
PRODUCT APPLICATION
COMPANY INFORMATION
PACKAGING & TRANSPORTATION
FAQ
