| US$999.00-1,399.00 | 2 Pieces (MOQ) |
| Model | Unit | T30ABMS | T30ABML | T30AFWS | T30AFWL | T30ABWS | T30ABWL | |
| Item | ||||||||
| Overall length | mm(in.) | 849(33.4) | 609(24) | 849(33.4) | ||||
| Overall width | mm(in.) | 399(15.7) | 358(14.1) | 399(15.7) | ||||
| Overall height | mm(in.) | 1134(44.6) | 1261(49.6) | 1134(44.6) | 1261(49.6) | 1134(44.6) | 1261(49.6) | |
| Transom height | mm(in.) | 381(15) | 508(20) | 381(15) | 508(20) | 381(15) | 508(20) | |
| Weight | Kg | 52 | 53.5 | 55.5 | 57 | 53.5 | 55.7 | |
| Full throttle operating range | r/min | 4500-5500 | 4500-5500 | 4500-5500 | ||||
| Maximum output | Kw (HP)@r/min | 22(30)@5000 | ||||||
| Idling speed (Neutral) | r/min | 1050-1150 | ||||||
| Engine type | Reed Valve | |||||||
| Cylinders | L2 | |||||||
| Displacement | cm 3 | 496 | ||||||
| Bore ×stroke | mm(in) | 72.0×61.0(2.83×2.40) | ||||||
| Ignition system | CDI | |||||||
| Control system | Tiller control | Remote control | Tiller control | |||||
| Starting system | Manual start | Electric start/Manual start | ||||||
| Gear positions | Forward-Neutral-Reverse | |||||||
| Gear ratio | 2.08 (27/13) | |||||||
| Trim and tilt system | Manual tilt | |||||||
| Fuel tank capacity | 24 | |||||||
| Maximum fuel waste | L /h | 14 | ||||||
| Mixing ratio | Fuel:Oil | 50:1 | ||||||
| Gear oil capacity | cm 3 | 320 | ||||||
| Propeller options* | in | 3-9 7 /8" x 11 1 /4" | ||||||
