Features
lSmall Size, Easy To Carry And Simple Installation
lBuilt-in Chargeable Lithium Battery Can Continuously Work 14 Hours
l4 Lines Display Velocity, Flow Rate, Volume And Meter Status
lClamp-on Mounted, Unnecessary Pipe Cutting Or Processing Interruption
lFluid Temperature Range -40℃~260℃
lBuilt-in Data Storage Is Optional
lSuitable For DN20-DN6000 Flow Measurement By Selecting Different Size Transducers
lBi-directional Measurement, Flow Range From 0.01m/s To 12m/s
Specification
Transmitter
Measuring Principle
| Transit-time
|
Velocity
| 0.01 - 12 m/s, Bi-directional Measurement
|
Resolution
| 0.25mm/s
|
Repeatability
| 0.10%
|
Accuracy
| ±1.0% R
|
Response Time
| 0.5s
|
Sensitivity
| 0.003m/s
|
Damping
| 0-99s (settable by user )
|
Suitable Fluid
| Clean or tiny amounts of solids, air bubbles liquid , Turbidity <10000 ppm
|
Power Supply
| AC: 85-265V, built-in chargeable lithium battery can continuously work 14 hours
|
Protection Class
| IP65
|
Operating Temperature
| -40℃ ~ 75℃
|
Enclosure Material
| ABS
|
Display
| 4X8 Chinese Or 4X16 English,Backlit
|
Measuring Unit
| meter,ft,m³,liter,ft³ ,gallon,barrel etc.
|
Communication Output
| Data Logger
|
Security
| Keypad Lockout, System Lockout
|
Size
| 212*100*36mm
|
Weight
| 0.5kg
|
Transducer
Protection Class
| IP67
|
Fluid Temperature
| Std. transducer: -40℃~85℃(Max.120℃)
|
High Temp: -40℃~260℃
|
Pipe Size
| 20mm~6000mm
|
Transducer Size
| S 20mm~50mm
|
M 40mm~1000mm
|
L 1000mm~6000mm
|
Transducer Material
| Std. Aluminum alloy, High Temp.(PEEK)
|
Cable Length
| Std. 5m (customized)
|
