CNC Machine Types Precision Spark Die Sinker EDM Machine for Sale

Negotiable 1 Piece (MOQ)

Basic Info.

Model NO.
140S+
Process Usage
Metal-Forming CNC Machine Tools
Certification
CE
Condition
New
Transport Package
Plywood Cae
Specification
CE
Trademark
DMNC
Origin
Beijing
HS Code
8456301010
Production Capacity
300sets/Year

Product Description

Quotation of 140S+ High Precision CNC die sinking EDM
Specifications of 140S+
Function configuration of controller
No. Function explanation
1 LCD, touch screen input
2 Simultaneous three axis control( with 4th axis control)
3 Super finish PIKA machining circuits-mirror surface machining function; fine current control circuits with better performance of large area super finish machining, at the same time, excellent performance of corner clearing
4 Expert machining parameters database: with high explosive power circuit, specially good for processing hard ally material)
Automatic and manual machining according to different combination of different material of electrode and workpiece: copper/steel, graphite 1/steel, graphite 2/steel, silver-tungsten/steel, copper-tungsten/steel, silver-tungsten/hard alloy, copper/zinc alloy, graphite/zinc alloy, copper/copper alloy.
5 AUTO machining function:
Input material of electrode and workpiece, machining area, shrinkage of electrode, required surface finish and etc Then control system automatically calculate machining parameters from rough machining to finish machining according to expert database.
6 Automatic positioning function:
End face positioning, cylinder center positioning, corner positioning, inner hole positioning, random three points positioning, discharging position self-decided positioning and etc.
7 Online measuring function:
Utilize automatic positioning function to do online measuring and amending to machined workpiece.
8 Automatic arcing removing circuit:
Real-time monitoring on the discharging status, if any tiny short circuit or arcing happens, system would remove arcing and give alarm
9 Safety control function:
Overload protection, code grammar detecting, oil level control, oil temperature control, automatic fire extinguisher
10 Power-off recovery function:
System can remember present position of coordinate, when suddenly power-off happens, present position can be kept.
