Features
1. MIG & MMA function in one machine.
2. Advanced IGBT technology, compact design, lightweight, and energy saving.
3. Digital display, precisely controlled welding current, stable welding process, and excellent welding characteristics.
4. Automatic over-current, over-heat and over-voltage protection.
5. Integrated design with a wire feeder built-in. Facilitate mobility operations.
6. Can be used with gas or without gas.
7. Applicable for welding low carbon steel and low alloy steel of different thickness.
8. Compete with MIG torch, electrode holder, earth clamp, face mask, hammer.
Technical Specifications
ITEM
| UNIT
| MIG-140F
| MIG-160F
| MIG-180F
| MIG-200F
|
Input Power Voltage
| V
| AC230V±10%
| AC230V±10%
| AC230V±10%
| AC230V±10%
|
Input Power Frequency
| Hz
| 50/60
| 50/60
| 50/60
| 50/60
|
Rated Input Capacity
| KVA
| 3.8
| 4.5
| 5.3
| 6.1
|
Output Current Range (MIG)
| A
| 40-140
| 40-160
| 40-180
| 40-200
|
Output Current Range (MMA)
| A
| 20-120
| 20-140
| 20-160
| 20-180
|
Load Voltage
| V
| 16-21
| 16-22
| 16-23
| 16-24
|
Rated Duty Cycle
| %
| 60
| 60
| 60
| 60
|
Wire Feed Speed
| M/min
| 3-15
| 3-15
| 3-15
| 3-15
|
Gas Flow
| L/min
| 15-20
| 15-20
| 15-20
| 15-20
|
Dimensions
| MM
| 442*184*246
| 442*184*246
| 442*184*246
| 442*184*246
|
weight
| Kg
| 8.8
| 9
| 9.5
| 10
|
Related products
Company Introduction
Certifications
Exhibition
Action now
Why choose Retop?
a. We are welding machine MANUFACTURER, so we can offer better price and after-sale service and shorter delivery date.
b. We use all new components,mosfet tube, diode, capacitor and so on imported components.
c. We adopt IGBT technology to decrease failure rate and it is convenient to repair the welding machine and reduce the cost of
repairing, we just need to change the bad pcb board.
d. We provide Warranty period of 1 year for all our items
