China Factory Supplier Vertical Mini Radial Drilling Machine (Z3032X8/1)

Product Description

China factory supplier vertical radial drilling machine (Z3032X8/1) Product Description
Main features:
Inner-outer column.
Mechnical clamping for the column and Hydraulic Speed Changing.
Spindle with auto-feeding.
coolant, work light, available.
Spindle Box machined by machining center.

Product Parameters

Specification of our radial drilling machine Z3032x8/1:

Model	Z3032×8/1,Z3040×8/1	Z3040×10/1
Max.Drilling capacity (mm)	32	40
Distance spindle axis to column generating line (mm)	320-820	320-1020
Diameter of column (mm)	200	200
Spindle taper	MT4	MT4
Spindle travel (mm)	240	240
Spindle speeds range (r/min)	75-1220	75-1220
Spindle speeds series	6	6
Range of Spindle feeds (r/min)	0.1-0.25	0.1-0.25
Mpindle Spindle feeds	3	3
Max.Distance spindle nose to working surface of base (mm)	320-900	320-900
Dimension of worktable (mm)	400×400×350	400×400×350
Dimension of base (mm)	1370×700×160	1370×700×160
Overall Size (mm)	1407×720×1885	1407×720×1885
Power of Main motor (kW)	1.5	1.5
G.W/N.W (kg)	1425/1200	1425/1230
Packing dimension (cm)	155×77×210	187×77×210

Standard Accessories
1.Box shape worktable
2.Taper Sleeve
3.Tool releasing wrench
4.Drift
5.Eyelet bolts
Optional Accessories:
1.Quick change chuck
2.Tapping Chuck
3.Grease Gun Detailed Photos

Warranty:
What about the spare part if the machine break down?
==about the machine break down, normally our policy will be as the under way
1) Our quality guarantee time is 12 months since the machine on board
2) During this period, if the machine break down owing our machine itself quality problem, we will prepare the spare parts and send to you by free within 5 days. all these will be by free.
3) If the break down is caused by the mis operation, we of course will supply you the spare parts, but we have to charge you the costs prices.

---
