Dmtg Automatic Speed Shift 1 Metro CNC Lathe Tool

Product Description

DMTG DT40 Dalian Machine Benchtop Automatic CNC Lathe Maquina Twin Spindles Slant Bed CNC Lathe Torno Cnc Turning Center

CAPACITY	Swing over bed	mm	580
	Max. turning length	mm	550,1055
	Max. turning diameter ( shaft/ disc)	mm	350
	Guideway type		Roller guide way
SPINDLE	Chuck size	Inch	8
	Spindle nose		ISOA2-6
	Spindle bore	mm	70
	Spindle speed	rpm	35-4000
	Spindle motor power	kw	11/15
	Spindle torque	Nm	105/140
	Max bar diameter	mm	51
TRAVEL	X-axis travel	mm	215
	Z-axis travel	mm	555/1055
	X-axis rapid traverse	m/min	30
	Z-axis rapid traverse	m/min	30
TOOL POST	Turret type and tool number		Hydraulic 12-station turret
	Tool shank size	mm	25x25
	Indexing time(adjacent/farthest)	s	0.31/0.78
TAILSTOCK	Diameter of tailstock quill	mm	50
	Tailstock quill travel	mm	140

---
