High Temperature Air & Liquid Flow Multifunction Fabric Dyeing Machine

Product Description

Ultra Low Energy Consumption Multi Flow Dyeing Machine

Product Description
The innovative MULTI-FLOW ECODYE is a high temperature, high pressure air & liquid dyeing machine, suitable for a wide range of knitted and woven fabrics: cotton, rayon nylon, tencel polyester, T/R, T/C, etc.
With its newly designed blower we were able to reduce the power consumption again and as well the volume (dB) at the dye-house. It saves up to 40% energy consumption compare to traditional muti flow dyeing machine. The design of MULTI-FLOW ECODYE is in line with the concept of green and sustainable development to make efforts to protect the environment.
Special Features
- Newly developed high performance, low noise inside blower for fabric transport & opening, lower the power consumption up to 40% compare to traditional air-flow machines.
- Modified lifting reel(winch)with reduced height , for less fabric tension.
Technical Details
- Main tank & liquor carrying parts are made of stainless 316L
- Touch screen controller
- Operating temperature 140ºC
- Adjustable chamber, machine load can be reduced up to 60%
- Minimum liquor ratio 1:2.5
- Fabric speeds of up to 600 m/min
- Electro-pneumatic operated valves
- Automatic seam detector
- Frequency controlled pump motor, winch & blower
- 1-6 fabric chambers per machine
- Chamber capacity around 250 KG
- Analog dosing
Programmable automated dosing of dyes and chemicals
- Control cabinet in stainless steel
- Electronic water meter
- Electronic measurement of liquor ratio
- Unloading winch & plaiter
Optional
- Second dosing tank
- Hot water stock tank, preparation of the complete process bath
- Auto self-cleaning filter
- Fast dosing system, bypass function
Blower power contrast table

Model	Traditional Multi Flow Machine	MULTI-FLOW
1-Chamber	18.5	15
2-Chambers	37	18.5
4-Chambers	75	45
6-Chambers	132	75

Machine picture

---
