Well-Sold Cks6140/Cks6440A/Cks6440b CNC Lathe

Product Description

Company Profile
Product Description
Product Name: Well-sold CK6140X CNC lathe
Brand machine with the 45° Overall high strength cast iron slant bed, smooth chip removal, good rigidity.
FANUC oi mate-TD CNC system
STANDARD ACCESSORIES:
FAUNC Oi mate-TC CNC system
10-position hydraulic turret
3-chuck 8 hydraulic chuck
7.5 KW Servo spindle motor
Auto chip removal device.
Hydraulic tail-stock
OPTIONAL ACCESSORIES:
GSK980TDb or KND-1000T or Siemens 801 CNC system
Auto chip removal device.
Spring chuck Product Parameters

Item	Unit	CKS6140	CKS6440B	CKS6440A	CKS6420
Max.swing over bed	mm	540	540	540	300
Max.swing over carriage	mm	270	270	270	150
Max.workpiece length	mm	550	235	235	190
Travel for X axis	mm	220	245	350	300
Travel for Z axis	mm	580	275	245	200
Positioning accuracy for X,Z	mm	X:0.016;Z:0.02	X:0.016;Z:0.02	X:0.016;Z:0.02	X:0.016;Z:0.02
Re- Positioning accuracy for X,Z	mm	X:0.007;Z:0.008	X:0.007;Z:0.008	X:0.007;Z:0.008	X:0.007;Z:0.008
Rapid feeding	m/min	12/16	12/16	12/16	10/10
Tool numbers	PCS	10	10	Gang tool	Gang tool
Main motor	KW	7.5	7.5	7.5	5.5
Max.spindle speed	r/min	4000	4000	4000	3500
Spindle bore	mm	65	65	65	58
Cannula bore	mm	Φ52	Φ52	Φ52	Φ42
External diameter tools	mm	20	20	16	16
Interior diameter tools	mm	25	25	20	20
Overall dimension	mm	2717×1580×1870	1860×1520×1725	1825×1705×1800	1780×1310×1720
Weigh	KG	3500	3000	3000	1800

Packaging & Shipping

---
