Cold laminating metallized 12 micron polyester aluminum foil

Product Details

Product Description

Product Description
Product Description:
The raw material of aluminum polyester tape is soft aluminum foil and a polyester film, compound with intaglio coating, slitting and rolling when aluminum foil polyester was done; the structure is a layer of aluminum foil in the two sides and a layer of polyester film in the middle. (AL/PET/AL)
Application: Apply to magnetic field with non-electromagnetic or precipitation static, such as communication cables, data cable, coaxial cable, internet cable and shielding of signal cable, can match with coating, it can be used in assemble shielding and grounding when aluminum foil polyester was cut.
Main specifications:

Specification	Composition			Elongation （%）	Tensile strength （Mpa）	Basis weight （g/m²）	Peel strength (N/cm)
Specification	AL	PET	AL	Elongation （%）	Tensile strength （Mpa）	Basis weight （g/m²）	Peel strength (N/cm)
32μm	7μm	12μm	7μm	35↑	6.3↑	61±10%	6.3↑
35μm	7μm	15μm	7μm	35↑	6.3↑	65±10%	6.3↑
36μm	9μm	12μm	9μm	35↑	6.3↑	74±10%	6.3↑
49μm	9μm	25μm	9μm	35↑	60↑	92±10%	6.3↑
55μm	12μm	15μm	12μm	35↑	60↑	94±10%	6.3↑
