| US$150.00-180.00 | 1 KM (MOQ) |
| Parameters | Specification | |
| Type | Cat6 SF/UTP | |
| Conductor | 23AWG | |
| Conductor | Material | Bare Copper |
| O.D (MM) | 1/0.57±0.0057 | |
| Insulation | Material | HDPE |
| Typical Thickness (mm) | 0.22 | |
| Min Thickness (mm) | 0.16 | |
| Outer Diameter (mm) | 1.02±0.05 | |
| Pairs | 1 | Blue /blue &white |
| 2 | Orange /Orange &white | |
| 3 | Green /green &white | |
| 4 | Brown /Brown &white | |
| Cable Shield | Strap | Polyester strap |
| Bare Copper Wire Braid | ≥65% | |
| Aluminum Foil Coverage (%) | 100 | |
| Inner Jacket | Material | PVC |
| O.D (mm) | 7.2 ± 0.5 | |
| Outer Jacket | Material | PE |
| Typical Thickness (mm) | 0.60 | |
| Min Thickness (mm) | 0.41 | |
| O.D (MM) | 8.4 ± 0.5 | |
| Color | Black | |
| Packing Length (M) | 305 ± 1% | |
| Impedance (ohms) | 100 ± 15 | |
| DC Resistance (ohms/1000ft) | Max 28.6 | |
| Capacitance (NF/1000ft) | 17.1 | |
| Velocity of Propagation (%) | 66 | |
| Elongation before aging (%) for PE jacket | ≥ 300 | |
| Elongation after aging (%) for PE jacket | ≥ 80 | |
| Frequency | Characteristic Impedance | Max Attenuation | Propagation Delay | Return Loss |
| MHz | Ohm | dB/100M | ns/100M | dB |
| 4 | 100±15 | 3.7 | 552 | 23 |
| 10 | 5.9 | 545.4 | 25 | |
| 16 | 7.5 | 543 | 25 | |
| 20 | 8.4 | 542 | 25 | |
| 31.25 | 10.6 | 540.4 | 23.6 | |
| 62.5 | 15.4 | 538.6 | 21.5 | |
| 100 | 19.8 | 537.6 | 20.1 | |
| 200 | 29 | 536.5 | 18 | |
| 250 | 32.8 | 536.3 | 17.3 |
