| Cylindrical Battery Pack Assembly Machine | ||
| Item No. | Product Name | Description |
| 1 | Internal Resistance Tester | 1. Voltage test V1: range : 0-4.999V 2. Voltage test V2: range : 0-29.99V 3. Resistance test R1: range : 0.1-200 mΩ 4. Resistance test R2: range :1-2000 mΩ |
| 2 | 6/13 Channel Automatic Battery sorting Sorter machine | 1.Sorting Speed:80PPM 2.Suitable for:all types of cylindrical cell |
| 3 | Insulation Paper Sticking Machine | 1.Productivity:4000pcs/h; single 4pcs 2.Suitable:one machine for one type cylindrical cell |
| 4 | Manual AC Pneumatic Spot Welder | 1.Welding Thickness:0.03-0.2mm 2.Maximum power output of transformer:15 KVA |
| 5 | Manual DC Pneumatic Spot Welder | 1. Welding Thickness:0.03-0.25mm 2. Maximum Output Short Circuit Current:5000A |
| 6 | Automatic 5000A/8000A Single Side Spot Welding Machine | 1. Spot Welding Speed:0.35s/point; 2800pcs / hour 2. X-Y-axis Travel:400*500mm (can be customized according to request) |
| 7 | Automatic 5000A/8000A Double Sides Spot Welding Machine | 1. Spot Welding Speed:0.35s/spot, 5500pcs/h 2.Y-Z-axis Travel:400*500mm (can be customized according to request) |
| 8 | Automatic 5000A/8000A Single Side Rotary Welding Head Spot Welding Machine | 1. Welding Material: pure nickel sheet: 0.03-0.2mm Nickel-plated steel strip :0.03-0.3mm 2. Maximum Spot Welding Speed:0.35S/point;2800pcs/h 3. Maximum Stroke Size Range: X:500mm,Y:400 mm,Z:35mm, R:180º The distance between tooling platform and welding needle can be adjusted by 300 mm. |
| 9 | Automatic 5000A/8000A Double Sides Rotary Welding Head Spot Welding Machine | 1.Rotary Welding Head:R:180º The distance between tooling platform and welding needle can be adjusted by 300 mm. 2. Welding Travel: Y: 500mm; Z; Z2:350mm(or 400mm) |
| 10 | Automatic Assembly Line Double Side Spot Welding Machine | Suitable for assembly line battery pack production |
| 11 | Battery Pack PVC Covering Machine | 1. Transmit Speed: 0-15m/min 2.Shrinking Speed:0-300C 3.Load-bearing:30kg |
| 12 | 30V 10A 20A Battery Pack Aging Cabinet | 1.Voltage testing range:4.5-30V 2.Charging range:50-10000mA 3.Discharging range:50-20000mA 4.Accuracy:±(0.2% of reading +0.2% of range) |
| 13 | 70V 5A 10A Battery Pack Aging Cabinet | 1.Voltage testing range:5-70V 2.Charging range:50-5000mA 3.Discharging range:50-10000mA 4.Accuracy:±(0.2% of reading +0.2% of range) |
| 14 | 100V 10A 20A Battery Pack Aging Cabinet | 1.Voltage testing range:10-100V 2.Charging range:50-10000mA 3.Discharging range:50-20000mA 4.Accuracy:±(0.2% of reading +0.2% of range) |
| 15 | Automatic Inject Printer | 1.Printing speed:320m/min 2.Non-contact printing distance:2-15mm 3.Max number of printing dots:34 |
| 16 | Battery Pack Comprehensive Tester | 1.Voltage testing range:10-100V 2.Charging range:50-10000mA 3.Discharging range:50-20000mA 4.Accuracy:±(0.2% of reading +0.2% of range) |
| 17 | BMS Tester | 1.Overcharge/Overdischarge Protection Voltage:0.5-5V 2.Overcharge Protection Current:0-50A 3.Over-discharge Protection Current:0-120A |
| 18 | 256 Channel 5V 2A 3A 5A 6A Battery Tester | 1.Current:0.05A-2A/3A/5A/6A 2.Voltage:0-5V 3.Channel:256 |
| 19 | 512 Channel 5V 2A 3A 5A 6A Battery Tester | 1.Current:0.05A-2A/3A/5A/6A 2.Voltage:0-5V 3.Channel:512 |
| 20 | 256/512 Channel 5V 3A 5A 6A Lithium Battery Tester With Energy Regenerative Function | 1.Current:0.05A-2A/3A/5A/6A 2.Voltage:0-5V 3.Channel:256/512 4.Lithium Battery Tester with Energy Regenerative Function |
| 21 | PVC Heat Shrink Wrapping Machine | 1.Film speed:50~70PCS/MIN 2.Film precision:±0.1MM |
