Product Details
Product Description
Product Description
Focus on DCS, PLC, robot control system and large servo system.
Main products: various modules / cards, controllers, touch screens, servo drivers.
Advantages: supply of imported original products, professional production parts,
Fast delivery, accurate delivery time,
The main brands include ABB Bailey, Ge / fuanc, Foxboro, Invensys Triconex, Bently, A-B Rockwell, Emerson, ovation, Motorola, xyvom, Honeywell, Rexroth, KUKA, Ni, Deif, Yokogawa, Woodward, Ryan, Schneider, Yaskawa, Moog, prosoft and other brands
Output Power Distribution The following procedures must be implemented where the controller or expander chassis contain TrustedTM Output modules: a Fit 2-off chassis trunking brackets to the fixing points on the rear of the chassis. Fixings are M5 x 6 CSK screws. Use only one screw per bracket. An example trunking bracket is shown right. These allow trunking to be mounted above the chassis, with clearance away from the fan tray. b Fit a TS35 DIN Rail 440mm long to the brackets on the rear of the chassis using the second chassis mounting points. Fixings are M5 x 8 Pan Head Taptite screws with large plain and crinkle washers. c Fit 40W x 40H x 385mm long trunking to the brackets fitted in a. above, using any of the three holes on the top of each bracket. The trunking should be mounted such that it is in line with the rear end of the chassis on the pivot side of the swingframe. Fixings are M5 x 8 Pan Head Taptite screws with large plain and crinkle washers. d Fit Output Distribution Units on the TS35 DIN Rail as required, and retain in position with 2-off end stops. The units must be fitted with insulated covers if the voltage exceeds 24V dc. Fit TrustedTM Power Distribution Unit(s) MCB 24V dc (Part No. T8292) as required to the TS35 DIN Rail fitted to the handle side of the swingframe and retain in position with 2-off end stops. Note that the units should be positioned as close as possible to the PSU. TrustedTM AN-T80003 TrustedTM System Mechanical Build Issue 1 Feb 07 AN-T80003 4 Completed Assembly The picture below shows a part assembled swingframe with three system chassis, three fan trays, trunking and rails fitted to brackets, MCBs for power distribution and T8290 power distribution units. TrustedTM AN-T80003 TrustedTM System Mechanical Build Issue 1 Feb 07 AN-T80003 5 I/O Connectors The I/O connectors to the chassis backplane are DIN 41612 type connectors, and are mounted in either a single or a double connector hood. The double connector hood enables TrustedTM I/O Interfaces (of the same type) to be installed in a Companion Slot configuration in adjacent slots. To install an I/O connector in the chassis backplane: 1. Ensure the correct connector and chassis backplane slot are selected 2. Ensure the associated chassis slot is not occupied by a module 3. Present the I/O connector to the chassis backplane slot, taking care to align the four lugs of the connector with the four cut-outs of the slot 4. Push the I/O connector in and upwards into the slot until the I/O connector latch engages with the chassis slot backplane-lip 5. Ensure that the I/O connector is secure in its chassis slot Connection at the other end of the cable may be via a similar connection or via a flying lead – see the appropriate Product Descriptions for full details of I/O cable types.
>>
