| US$36,000.00-40,000.00 | 1 sets (MOQ) |
| odel | Operating weight | kg | 22500 |
| Bucket capacity | m³ | 1 | |
| Engine | Engine model | v | |
| Direct injection | / | √ | |
| 4×Strokes | / | √ | |
| Water cooling | / | √ | |
| Turbocharging | / | √ | |
| Cylinders | / | 6 | |
| Output power of engine | Kw/rpm | 124/1950 | |
| Max.torque/engine | N.m/rpm | 551/1600 | |
| Displacement | L | 6.494 | |
| Mian pertormance | Travel speed | km/h | 5.5/3.3 |
| Slewing speed | r/min | 13.3 | |
| Gradient capability | ° | ≤35° | |
| Ground pressure | kPa | 45.5 | |
| Digging capacity of tcuket | kN | 138 | |
| Digging capacity of tcuket rod | kN | 103 | |
| Max.traction | kN | 184 | |
| Hydraulic system | Pressure of pilot system | Mpa | 3.9 |
| Oil volume | Fuel tank capacity | L | 360 |
| Hydraulic tank capacity | L | 220 | |
| Engine oil volum | L | 25 |
